Unpacking and Installing the Chassis

Figure 49: Installing the Cisco ASR 9904 Router Chassis in a Standard 2-Post Rack

The figure below shows the orientation of the Cisco ASR 9906 Router chassis to the rack posts and components

used in the installation.

Installing the Chassis in a 2-Post Rack

Six screws per side (minimum) to attach the router

chassis to the rack.

Unpacking and Installing the Chassis
