Summary of Contents for Avidsen 123881
- Page 1 720P WiFi IP camera Outdoor ref. 123881 720p 720p #REC (Not included) (Not included) 2.4GHz 2.4GHz Available on the Free available on Free available o ee available ee available on ee available o ee available on ee available o Google Play...
-
Page 2: Table Of Contents
CONTENTS A - SAFETY INSTRUCTIONS 1 - OPERATING PRECAUTIONS 2 - MAINTENANCE AND CLEANING 3 - RECYCLING B - PRODUCT DESCRIPTION 1 - KIT CONTENTS 2 - CAMERA 3 - MAINS ADAPTOR C - INSTALLATION 1 - INSTALLING THE CAMERA 2 - CONNECTING THE CAMERA 3 - INSERTING A MICRO SD CARD (NOT INCLUDED) D - CONFIGURATION... - Page 3 F - RESETTING G - FAQ H - TECHNICAL AND LEGAL INFORMATION 1 - TECHNICAL CHARACTERISTICS 2 - WARRANTY 3 - HELP AND ADVICE 4 - PRODUCT RETURNS/AFTER SALES SERVICE 5 - DECLARATION OF CONFORMITY...
-
Page 5: A - Safety Instructions
720P WIFI IP CAMERA A - SAFETY INSTRUCTIONS 1 - OPERATING PRECAUTIONS 3 - RECYCLING • The cameras must not be installed where the This logo denotes that devices which are lens filter may be vulnerable to scratching and no longer in use must not be disposed of dirt. -
Page 6: B - Product Description
720P WIFI IP CAMERA B - PRODUCT DESCRIPTION 1 - CONTENTS OF THE KIT Camera Wall plugs for attaching the base Mains adaptor Screws for attaching the base Antenna 2 - CAMERA Front view Antenna Adjustable stand Protective Shield 12 VDC 1A mains adaptor power supply included in the kit Lens Green detection indicator Light for night vision... - Page 7 720P WIFI IP CAMERA B - PRODUCT DESCRIPTION 3 - MAINS ADAPTER A 230Vac 50Hz / 12Vdc 1A mains adapter is supplied in the kit for the camera power supply. Do not use other power supplies as they could damage the camera and invalidate the warranty.
-
Page 8: C - Installation
720P WIFI IP CAMERA C - INSTALLATION 1 - INSTALLING THE CAMERA • Mount the camera using suitable screws and wall plugs for the type of surface (the screws and plugs supplied are suitable for solid walls). • Make sure the camera is properly secured to prevent it from falling. Wall mounting Ceiling mounting 2 - CONNECTING THE CAMERA... -
Page 9: Inserting A Micro Sd Card (Not Included)
720P WIFI IP CAMERA C - INSTALLATION 3 - INSERTING A MICRO SD CARD (NOT INCLUDED) Your camera has a micro SD card slot, which gives it an internal storage memory. The maximum size is 64 GB. This use is optional, but it is necessary if you want the camera to record independently. Tool needed: Thin, cross-headed screwdriver with PH1 bit holder (Philips). -
Page 10: D - Configuration
720P WIFI IP CAMERA D - CONFIGURATION 1 - CONFIGURING THE CAMERA AND Fill in the “E-mail” [Email] and “Mot de passe” ADDING IT TO THE APP [Password] fi elds Email: “indiquez une adresse e-mail valide” [enter a Download the Avi-cam IP application from valid email address]. -
Page 11: Access To All Settings
720P WIFI IP CAMERA D - CONFIGURATION Configuration menu for recording quality on the micro SD card Implementing a locking scheme to protect your camera’s live viewing and recordings. Allows you to add a guest account on your camera to allow others to access your camera Changing the camera’s WiFi network: to add a new WiFi network, you must first connect... -
Page 12: Movement Detection And Alerts
720P WIFI IP CAMERA D - CONFIGURATION You will receive the following information: (iOS) Return to the list of cameras Menu to rename your camera (Android) Allows you to add information about your camera, location, owner, (useful if you share your camera with a guest account) Displays your camera’s current IP address Displays your camera’s current MAC address... -
Page 13: Settings For Recording On The Micro Sd Card
720P WIFI IP CAMERA D - CONFIGURATION 2.4 - Settings for recording on the micro SD card To access the recording on the micro SD card menu, click on the icon on the camera, and press “Stockage vidéo” [Video storage]. Return to the list of cameras Enable/disable continuous recording on micro SD card (not included) -
Page 14: E - Operation
720P WIFI IP CAMERA E - OPERATION 2 - PLAYING CAMERA RECORDINGS From the list of cameras , click on the “relecture” [playback] button under the camera name. Select the date to view the corresponding video. *Confi rm with OK (Android) List of cameras Alerts Profi les menu and local recording... -
Page 15: Playing Alert Videos
720P WIFI IP CAMERA E - OPERATION Return to the list of cameras Enables full-screen mode Video viewing Video progress bar Triggers video recording (stored on your smartphone) Starts playing the alert record Trigger taking a picture (stored on your smartphone) Note: During live viewing, you can take photos or record the video on your Smartphone. -
Page 16: Album Management
720P WIFI IP CAMERA E - OPERATION Pressing “gestion contenu” [content management] displays new Options Exits the content management menu Selects all available content Changing your password and confi guring password recovery options in case of Pressing an image or video selects or forgotten password (security... - Page 17 - If your Android device has an SD card: SD card / Avidsen / screenshot / name of your account / If your Android device doesn’t have an SD card:...
-
Page 18: F - Resetting
720P WIFI IP CAMERA F - RESETTING In a problem occurs, the WiFi configuration can be reset by holding the SET button for 3 to 5 seconds. Once reset, the camera will start up again. After 30 seconds, it is available for reconfiguration. Note: Pressing the SET button does not delete the camera pairing from your app... -
Page 19: G - Faq
720P WIFI IP CAMERA G - FAQ Symptoms Possible causes Solutions Please contact the technical You have an out-of-date or support of your device’s incompatible version of Android manufacturer in order to obtain a on your device recent Android version. Unable to install the avi-cam IP Google Play checks all the key app on my Android device... - Page 20 720P WIFI IP CAMERA G - FAQ Symptoms Possible causes Solutions Check the video settings and Poor quality or shaky image Incorrect video settings reduce/increase the quality if necessary Movement detection is triggered Unsuitable movement detection Reduce the sensitivity of unnecessarily settings detection.
-
Page 21: H - Technical And Legal Information
H - TECHNICAL AND LEGAL INFORMATION 1 - TECHNICAL CHARACTERISTICS Camera 12V DC/1A Power supply WiFi IEEE 802.11 g/n 2.4Ghz WPA/WPA2 compatible Wireless network interface ¼’’ CMOS Optical sensor Minimum luminous intensity 0 lux Automatic (dusk-to-dawn sensor) Night vision Range: 25m f: 2.8mm Lens Diagonal: 110°... -
Page 22: Product Returns/After Sales Service
5 - DECLARATION OF CONFORMITY Per the RED directive Smarthome France hereby declares that the equipment designated below: 720P outdoor WiFi IP camera 123881 Complies with the RED directive and its conformity has been assessed pursuant to the applicable standards in force:... - Page 24 Smarthome France 19 avenue Marcel Dassault ZAC des Deux Lions - 37200 Tours - France...
