V1-10.16
Assembly Instructions
(W x D x H): 1.60m x 0.345m x 0.405m
Product Name: Madison Bench
Pressure Treated products should not be treated with any other products for the first month.
PLEASE KEEP THIS INSTRUCTION
Zest4Leisure
01352 752555 option 1 – sales@zest4leisure.co.uk
Advertisement
Table of Contents
Related Manuals for Zest 4 Leisure Madison Bench
Summary of Contents for Zest 4 Leisure Madison Bench
- Page 1 V1-10.16 Assembly Instructions (W x D x H): 1.60m x 0.345m x 0.405m Product Name: Madison Bench Pressure Treated products should not be treated with any other products for the first month. PLEASE KEEP THIS INSTRUCTION Zest4Leisure 01352 752555 option 1 – sales@zest4leisure.co.uk...
- Page 2 Madison Bench Assembly Instructions Requires 2 person assembly. Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit required in order for you to drill all screw holes before construction. The colour version of this document can be downloaded from: www.zest4leisure.co.uk/downloads/category/C1...
- Page 3 Repeat procedure on opposite end of Bracing B with remaining Leg Assembly A. (See Figs. 1a & 1b) Position leg assembly centrally onto Seat Assembly C using 4no 80mm screws (2no per Leg Assembly A) Madison Bench is now complete.
