MAKS Keyfob Quick Start Manual

WIRELESS KEY FOB
• compact key fob
• elegant design, slim profile
• three buttons to control the arming modes
• one of the buttons can be reprogrammed
• 868,0 ... 868.6MHz, several channels
for redundancy, distance up to 100 m outdoors
• CR2032 battery
• up to five years' service life
The wireless key fob is designed to control the MAKS PRO security system. It has two buttons for arming and disarming, one soft key,
and a LED indicator for interaction with the alarm user. Can be used as an alarm button.
Radio communication
Key fob has a receiving and transmitting device 868.0 ... 868.6MHz, with several channels for redundancy.
Secure two-way radio communication. Distance - up to 100 m in the open space.
Using the key fob
The Key fob has protection against false alarms, quick clicks are ignored, so to execute a command the button should be kept pressed
for a short time.
To arm the system, press the "Arming" button
To disarm and disable the alarm, press the "Disarming" button
To arm the system in "Arm Stay" mode, press and hold the "Disarming" button
The soft key is disabled by default
Configuration and registration in the system
The key fob works only with the center of the MAKS PRO wireless security system, connection to other systems is not provided. The key
fob is registered for the user of the security center and is configured using the MAKS SETUP mobile application.
To register the key fob:
1. Place the key fob no further than 2 m from the MAKS PRO security center. Registration runs on the lowest possible power to avoid
the influence of neighboring systems which may be being set up nearby
2. Start the MAKS SETUP application, select the required MAKS PRO from the list
3. On the "Users" tab , create a new user or select an existing one from the list
4. Press the "Add key fob" button, and then press and hold any button on the key fob for about 10 seconds until the indicator flashes
green
5. Set up the key fob functions
Characteristics
ISM wireless interface,
up to 100 m
Power
service life
Operating temperature range
Case color
Dimensions
Weight
868,0... 868,6 MHz, up to 2 m, secure two-way
communication with 256 bit key
CR2032 battery, 3V
up to 5 years
from -10°C to +40°C
white, black
Ø 39 x 9 x 57 mm
15 grams
info@kdsystemy.eu, www.kdsystemy.eu
and then press the "Arming" button
Features
Key fob can only control one group
KD SYSTEMY SP. Z O.O.
Nieklanska str. 35/1,
03-924 Warsaw, Poland
MAKS SETUP
