MAKS Siren Quick Manual

WIRELESS SIREN
• miniature siren for indoor use
• elegant design
• available in two colors
• sound pressure level - 85 dB at a distance of 1 m
• arming confirmation indicator connection
• 868,0 ... 868.6MHz, several channels for
redundancy, range up to 2000 m
• power supply - two CR123A batteries
• up to five years of service
• easy and fast installation
This wireless siren is designed for alarm notification when the wireless
detectors of MAKS PRO security center are triggered.
It is installed indoors to warn about the danger or scare off intruders.
The device has contacts for connecting the arming information LED and
external reed switch.
Radio communication
The siren transceiver operates in several channels of 868.0 ... 868.6 MHz
band for redundancy
Secure two-way radio communication.
Distance - up to 2000 m in the open space.
Three gradations of power, the maximum - up to 20 mW.

Setting up

The siren operates only with the MAKS PRO wireless security system center,
connection to other systems is not provided.
The siren is connected to the security center and configured using the
MAKS Setup mobile application. The volume and running time of the
audible alarm are adjustable.

Features

The time for switching on the built-in indicator or external arming informa-
tion LED is 15 seconds.
For "Armed" status indication, you can set the built-in indicator or external
LED to flash once every 10 seconds.
If MAKS PRO is in the "Armed (Stay)" mode, the alarm sound will always be
activated at the minimum volume.
In the event of an alarm, the MAKS wireless siren will be activated no later
than in 10 seconds (communication period with the security center).
For more information on setting up and operating the
device, please visit www.maks.systems

Characteristics

ISM wireless interface, up to 2000 m
secure two-way communication
Power
(lithium batteries included)
consumption in standby mode
radio consumption
alarm consumption
service life of battery
Sound pressure level at 1 m
Operating temperature range
Case color
Dimensions
Weight
Connection to MAKS Siren
distance (cable length) to external
elements
Volume levels, adjustable
Light indication, adjustable
868.0... 868.6 MHz
key - 256 bits
two CR123A, 3V batteries
no more than 5 µA
no more than 35 µA
no more than 70 µA
up to 5 years
at least 85 dB
from -10°C to +55°C
white, black
84.5 x 84.5 x 24.3 mm
no more than 1.5 m
external LED and reed switch
не більше 1,5 м
3
built-in or external
indicator
