BIGHORN SRCC2220 Assembly Instructions & User Manual

Adjustable grill charcoal bbq
Hide thumbs

Advertisement

Quick Links

Download this manual
Adjustable Grill Charcoal BBQ
Assembly Instructions & User's Manual
ITEM# SRCC2220 (PLU#075596 )
Please keep this instruction manual for future reference
Warning:
!
Adult assembly required.
Keep screws and parts out of reach of children.
FOR OUTDOOR USE ONLY
(Made in China)

Advertisement

loading
Need help?

Need help?

Do you have a question about the SRCC2220 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIGHORN SRCC2220

Summary of Contents for BIGHORN SRCC2220

  • Page 1 Adjustable Grill Charcoal BBQ Assembly Instructions & User’s Manual ITEM# SRCC2220 (PLU#075596 ) Please keep this instruction manual for future reference Warning: Adult assembly required. Keep screws and parts out of reach of children. FOR OUTDOOR USE ONLY (Made in China)

  • Page 2: General Warning And Safety Information

    GENERAL WARNING AND SAFETY INFORMATION not allow children to use grill. Keep a fire extinguisher accessible at all times while Only use charcoal lighting fluid. Never use gasoline, operating grill. alcohol or other highly volatile fluids to ignite Never leave grill unattended while in use. charcoal.

  • Page 3: Parts List

    PARTS LIST Item No. Qty Description Item No. Qty Description Item No. Qty Description Hood assembly Damper Cart brace-front Hood handle Ash tray handle Base panel Hinge assembly Crank handle assembly Wheel Left panel of firebox Cooking grate Left leg-front Rear panel of firebox Charcoal tray Left leg -rear...

  • Page 4: Hardware List

    HARDWARE LIST HARDWARE LIST Handle Flat washer qty-2 HARDWARE LIST Page 3...
  • Page 5 ASSEMBLY INSTRUCTIONS Before assembly read instructions carefully. Assemble grillon a clean, flat surface. This unit is heavy. DO NOT ASSEMBLEWITHOUT ASSISTANCE. GET A HELPER! Tools needed for assembly: Adjustable Wrench Philips Head Screwdriver STEP 1 Do not tighten screws all the way. Legs may need to be adjusted later.
  • Page 6 STEP 3 Do not tighten screws all the way. Attach cart brace assembly -rear(18) into the cart assembly using M6 x12(A) and washers (O) as shown. STEP 4 Attach base panel (23) into the cart assembly using M5x15 (L), lock washers(N) and flat washers(M) as shown.
  • Page 7 STEP 6 Attach left panel of firebox(5) into front panel of firebox(8) using M6 x12(A) as shown. Repeat step on right panel of firebox(7) into the firebox assembly. STEP 7 Attach rear panel of firebox(6) into the firebox using M6 x12(A) as shown. STEP 8 Attach charcoal door assembly (9) into panel of firebox as shown using...
  • Page 8 STEP 9 1.Attach the damper(11) into the front panel of firebox(8) using M6 step screws(C) and M6 nuts(D) as shown. 2.Attach the damper handle(10) into the . damper(11) using M4 nylon screw(E) and M4 nylon nut(F) as shown. 3.Repeat steps on damper(11) and damper handle(10) into the hood(1).
  • Page 9 STEP 11 1.Attach charcoal tray arm assembly(17) into the front panel of firebox(8) using M6x12(A ) as shown. 2.Thread crank(14) through hole on the front panel of firebox(8) using cotter pin(G) as shown. STEP 12 Attach the charcoal tray(16) into the charcoal tray arm assembly(17) using M6 x12 (A) as shown.
  • Page 10 STEP 14 Note: Attach both ends of hood handle before fully tightening hex flange nuts. 1.Attach the hood handle(3) into the hood(1) using M6x12(A) and flat washer(O) and Handle flat washer(K). 2.Attach temperature gauge (2) into the hood(1) as shown. Note: the temperature gauge is supplied Wing nut with one washer and one wing nut.
  • Page 11 STEP 16 Attach side table(30) into the firebox using M6 x12(A) as shown. Repeat step on opposite side for remaining side shelf. STEP 17 1.Attach ash tray handle(13) into the ash tray (12) using M4x10(I) . 2.Insert the ash tray assembly into the bottom of firebox as shown.
  • Page 12 FREQUENTLY ASKED AUESTION Q: My grates have rust on them. How do I get rid of it? brass or stiff bristle brush before grilling. Future build-up If rust occurs, clean with a steel brush. Reapply can be avoided by simply wiping the grill lid while slightly vegetable shortening and heat as indicated above.
  • Page 13 GRILL OPERATION CAUTIONS The use of alcohol, prescription or non-prescription Avoid bumping or impacting grill. drugs may impair the user's ability to properly Keep your hands, hair and face away from burning assemble or safely operate this grill. charcoal. Grill lid and body are HOT while in use and during This grill has an open flame.
