BIGHORN SRCG16003 Assembly Instructions & User Manual

Heavy-gauge horizontal smoker
Hide thumbs

Advertisement

Table of Contents

Heavy-Gauge Horizontal Smoker
Assembly Instructions & User's Manual
Please keep this instruction manual for future reference
K e e p s c r
Customer Service: (866) 814-0585, 8:00am to 8:00pm, Eastern Standard Time
DO NOT RETURN TO PLACE OF PURCHASE
ITEM# SRCG16003
Warning:
!
A d u l t a s s e
m b l y r e q u i r e d .
e w s a n d p a r t s o u t o f r e a c h
FOR OUTDOOR USE ONLY
Monday thru Friday
(Made in China)
o f c h i l d r e n .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRCG16003 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIGHORN SRCG16003

Summary of Contents for BIGHORN SRCG16003

  • Page 1 Heavy-Gauge Horizontal Smoker Assembly Instructions & User’s Manual ITEM# SRCG16003 Please keep this instruction manual for future reference Warning: A d u l t a s s e m b l y r e q u i r e d .

  • Page 2: Table Of Contents

    Table of Contents Safety Warnings………………………………………......…………………………………...........2 Exploded View…………………………………………....………………..................4 Parts and Tools....................................5 Assembly Instructions..................................7 Preparation For Use & Lighting Instructions............................19 Operating Instructions..................................21 After Use Safety....................................26 Proper Care & Maintenance................................26 Warranty Information..................................27 Note: Before beginning assembly of pro duct, make sure all parts are present. Compare parts with package content list and hardware contents.

  • Page 3: Safety Warnings

    Safety Warnings IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE A ND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMB O L IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL, P AY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
  • Page 4 Safety Warnings WARNING • Check grease level in grease cup often and empty or change when / full. Use extreme caution as the smoker, grease cup and its contents will be hot. • When grilling, grease from meat may drip into the charcoal and cause a grease fire. If this should happen close lid to suffocate the flame.

  • Page 5: Exploded View

    Exploded View CALIFORNIA PROPOSITION 65 WARNING This product contains chemicals, including lead in the brass of certain component parts, that are known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling. When used, this product emits fuel combustion chemicals that are known to the State of California to cause cancer, and birth defects or other reproductive harm.

  • Page 6: Parts And Tools

    Part List Part # Description P icture Part # Description P icture Ash Drawer Handle Cooking Grates Air Vent Charcoal Grates Wheel Axle Temperature Gauge Short Legs Smoking Chamber Lid Wheels Bottle Shelf Smoking Chamber Long Legs Firebox Support Front Table Bracket R Front Table Bracket L Front Table Grease Cup Holder...
  • Page 7 Hardware Hardware # Description Picture M6 x 12 Bolt M5 x 12 Bolt M12 Nut M6 Nut M6 Lock Nut (Silver) M5 Nut Flat Washer Tools Required Phillips Head Screwdriver (Not included) Adjustable Wrench (Not included)

  • Page 8: Assembly Instructions

    Assembly Instructions r. Lay bly area. Choose a good, cleared assembly area and get a friend to help you put your smoker together. Lay cardboard down to protect smoker finish and assembly area. Step 1 Washer Step 1 Bolt Smoking chamber Remove the lid from the smoking chamber by removing bolt and washer and sliding the hinge pins on the lid out of the hinge holes on the cooking chamber.
  • Page 9 Assembly Instructions Step 4 Step 4 Attach wheels to legs with wheel axle and M12 nuts (CC). M12 Nut Wheel axle Hardware Used 2pcs M12 Nut Step 5 Step 5 Attach firebox support to short legs with M6 x 12 bolts (AA). Firebox support Hardware Used M6 x 12 Bolt...
  • Page 10 Assembly Instructions Step 6 Step 6 Firebox lid stop Attach firebox lid stop to firebox top with M6 x 12 bolt (AA) and M6 nut (DD). Hardware Used M6 x 12 Bolt M6 Nut Step 7 Step 7 Attach firebox base, heat insulation cottons 1 and heat insulation cottons 2 to firebox top with M6 x 12 bolts (AA).
  • Page 11 Assembly Instructions Step 9 Step 9 Attach firebox assembly to smoking chamber by aligning the slots on the smoking chamber to the two M6 x 12 bolts and slide into place as shown. M6 x 12 Bolt Step 10 Step 10 Attach firebox to cooking chamber with M6 x 12 bolts (AA).
  • Page 12 Assembly Instructions Step 12 Step 12 Attach side handle to the smoking chamber with M6 x 12 botls (AA) and M6 nuts (DD). Hardware Used M6 x 12 Bolt 4pcs M6 Nut 4pcs Step 13 Step 13 Attach smoke stack and smoke stack gasket to the smoking Cap nut Spring chamber with M6 x 12 bolts (AA) and M6 nuts (DD).
  • Page 13 Assembly Instructions Step 14 Step 14 Attach bottle opener to smoking chamber with M5 x 12 bolts (BB) and M5 nuts (FF). Hardware Used M5 x 12 Bolt 2pcs M5 Nut 2pcs Step 15 Step 15 Insert grease cup holder through the hole inside the smoking chamber on the left side to hang under the smoking chamber.
  • Page 14 Assembly Instructions Step 16 Step 16 Attach front table bracket L to smoking chamber with M6 x 12 bolts (AA) and M6 nuts (DD). Attach front table bracket R by inserting the hooks of front table ends through the slots on front table bracket R & L as shown, and then attaching to smoking chamber with M6 x 12 bolts (AA) and M6 nuts (DD).
  • Page 15 Assembly Instructions Step 18 Step 18 Attach smoking chamber lid by sliding the hinge pins into the lid hinge holes on the smoking chamber as shown. Secure with one hinge bolt and one washer. Bolt Washer Step 19 Step 19 Remove pre-attached bolts and nuts from firebox lid handle Then attach firebox lid handle to the firebox lid with two bolts, nuts and washers.
  • Page 16 Assembly Instructions Step 20 Step 20 Remove pre-attached hinge bolt and washer from firebox lid hinge pins. Then attach firebox lid by sliding the hinge pins into into the lid hinge holes on the firebox chamber as shown. Washer Secure with one hinge bolt and one washer. Bolt Step 21 Step 21...
  • Page 17 Assembly Instructions Step 22 Step 22 Attach ash drawer handle to ash drawer with M5 x 12 bolts (BB) and M5 nuts (FF). Hardware Used M5 x 12 Bolt 2pcs 2pcs M5 Nut Step 23 Step 23 Insert ash drawer assembly into firebox assembly as shown.

  • Page 18: Cooking Grates 3

    Assembly Instructions Step 24 Step 24 Attach four "S" hooks to side handle. Step 25 Step 25 Place three charcoal grates into the smoking chamber Place three cooking grates over the charcoal grates. Place firebox charcoal grate into the firebox. Place two firebox cooking grates over the charcoal grate.
  • Page 19 Assembly Instructions Heavy Gauge Horizontal Smoker (Assembled)

  • Page 20: Preparation For Use & Lighting Instructions

    Preparation For Use & Lighting Instructions PLACE THE GRILL OUTDOORS ON A HARD, LEVEL, NON-COMBUSTIBLE SURFACE AWAY FROM ROOF OVERHANG OR ANY COMBUSTIBLE MATERIAL. NEVER USE ON WOODEN OR OTHER SURFACES THAT COULD BURN. PLACE THE GRILL AWAY FROM OPEN WIN DOWS OR DOORS TO PREVENT SMOKE FROM ENTERING YOUR HOUSE.
  • Page 21 Preparation For Use & Lighting Instructions IF USING CHARCOAL CHIMNEY STARTER, PROCEED TO STEP 8. , follow all manufacturer’s warnings and instructions regarding the use of their product. Start with 8 pounds of charcoal in cooking chamber and 3.5 1” to 2” and smokestack damper halfway. Step 5 Step 6 With grill lids open, stand back and carefully light charcoal and allow to burn...

  • Page 22: Operating Instructions

    Operating Instructions PLACE THE GRILL OUTDOORS ON A HARD, LEVEL, NON-COMBUSTIBLE SURFACE AWAY FROM ROOF OVERHANG OR ANY COMBUSTIBLE MATERIAL. NEVER USE ON WOODEN OR OTHER SURFACES THAT COULD BURN. PLACE THE GRILL AWAY FROM OPEN WIN DOWS OR DOORS TO PREVENT SMOKE FROM ENTERING YOUR HOUSE. IN WINDY WEATHER, PLACE THE GRILL IN AN OUTDOOR AREA THAT IS PRO TECT ED FROM THE WIND.
  • Page 23 Operating Instructions WARNING: Charcoal lighting uid must be allowed to com plete ly burn off prior to closing rebox lid and cooking chamber door (approximately 20 minutes). Failure to do this could trap fumes from charcoal lighting uid in smoker and may result in a ash- re or explosion when lid or door is opened.

  • Page 24: Firebox Lid

    Operating Instructions • Always use a meat thermometer to ensure food is fully cooked before removing from smoker. Grilling In Cooking Chamber Step 1 Remove cooking grills from firebox and set aside. Place charcoal grates in bottom of cooking chamber. Step 2 Follow the instructions below carefully to build a fire.
  • Page 25 Operating Instructions IF USING LIGHTER FLUID, PROCEED TO STEP 8 If using pre-treated charcoal, follow all manufacturer’s warnings and instructions regarding the use of their product. Start with 8 pounds of charcoal on charcoal grates. Open the firebox air shutter approximately 1”...
  • Page 26 Operating Instructions Adding Charcoal/Wood Additional charcoal and/or wood may be re quired to maintain or increase cooking tem per a ture. During Cooking Adding Charcoal/Wood in Firebox Step 1 Stand back and carefully open firebox lid. Use caution since flames can flare-up when fresh air suddenly comes in contact with fire.

  • Page 27: After Use Safety

    After-Use Safety WARNING • Always allow smoker and all components to cool completely before handling. • Never leave coals and ashes in smoker unattended. Make sure coals and ashes are completely extinguished before removing. • Before smoker can be left unattended, remaining coals and ashes must be removed from smoker. Use caution to protect yourself .

  • Page 28: Warranty Information

    Warranty Information F or 1 - y ea r f rom d a t e of p u rc h a s e, T h e Sh ineric h w a rra nt s t h e Big Horn Smoker a ga ins t d ef ec t s d u e t o w orkma ns h ip or ma t eria l s t o t h e origina l p u rc h a s er.
