SF2 Series
INDEX
1. GENERAL INFORMATION .......................................................................................... 1
1.2. How to choose the device ................................................................................... 3
1.3. Typical applications ............................................................................................. 5
1.4. Safety information ............................................................................................... 6
2
INSTALLATION MODE................................................................................................ 7
2.2. General information on device positioning .......................................................... 8
2.2.1.
Minimum installation distance .............................................................. 10
2.2.2.
Minimum distance from reflecting surfaces .......................................... 12
2.2.3.
Installation of several adjacent safety light curtains ............................. 14
2.2.4.
Use of deviating mirrors........................................................................ 15
3. MECHANICAL MOUNTING ....................................................................................... 16
4. ELECTRICAL CONNECTIONS ................................................................................. 18
4.1. Notes on the connections.................................................................................. 19
4.2. TEST timing diagrams....................................................................................... 20
5. ALIGNMENT PROCEDURES .................................................................................... 23
5.1. Correct alignment procedure (AUTOMATIC RESTART) .................................. 23
5.2. Correct alignment procedure (MANUAL RESTART) ........................................ 25
6. RESTART MODE ....................................................................................................... 27
7. DIAGNOSTIC FUNCTIONS ....................................................................................... 29
7.1. Visualisation of the functions............................................................................. 29
7.2. Fault messages and Diagnostics ...................................................................... 30
8. CHECKS AND PERIODICAL MAINTENANCE ......................................................... 31
8.1. Maintenance...................................................................................................... 31
8.2. General information and useful data ................................................................. 32
8.3. Warranty............................................................................................................ 32
9. TECHNICAL DATA .................................................................................................... 33
10. LIST OF THE AVAILABLE MODELS........................................................................ 34
11. DIMENSIONS ............................................................................................................. 35
12. ACCESSORIES.......................................................................................................... 36
Instruction Manual
safety light curtain.................................. 1
Advertisement
Table of Contents
Summary of Contents for SAFEasy SF2 Series
-
Page 1: Table Of Contents
SF2 Series Instruction Manual INDEX 1. GENERAL INFORMATION ..................1 1.1. General description of the SAFEasy safety light curtain........1 1.2. How to choose the device ................... 3 1.3. Typical applications ..................... 5 1.4. Safety information ....................6 INSTALLATION MODE....................7 2.1. -
Page 2: General Information
1.1. General description of the SAFEasy safety light curtain The SAFEasy safety light curtains – SF2 Series – are optoelectronic multibeam devices that are used to protect working areas that, in presence of machines, robots and automatic systems in general, can become dangerous for operators that can get in touch, even accidentally, with moving parts. - Page 3 DATASENSOR Sales Technical Service for any necessary information relative to the functioning of the SF2 series light curtains and the safety rules that regulate the correct installation (see section 8 “Checks and periodical...
-
Page 4: How To Choose The Device
Instruction Manual SF2 Series 1.2. How to choose the device There are at least three different main characteristics that should be considered when choosing a safety light curtain: • The resolution strictly depending on the part of the body to be protected. - Page 5 SF2 Series Instruction Manual • The height of the protected area It is important to distinguish between “Height of the sensitive area” and “Height of the controlled area” (Fig.3). - The height of the sensitive area is the distance between the lower and the upper limits respectively of the first and the last lens.
-
Page 6: Typical Applications
Instruction Manual SF2 Series 1.3. Typical applications The SAFEasy safety light curtains are used in all automation fields where it is necessary to control and protect the access to dangerous zones. In particular they are used to stop the moving mechanical parts of:... -
Page 7: Safety Information
SF2 Series Instruction Manual 1.4. Safety information The following points must be observed for a correct and safe use of the SAFEasy safety device: • The stopping system of the machine must be electrically controlled. • This control system must be able to instantly stop the dangerous movement of the machine during all the phases of the working cycle. -
Page 8: Installation Mode
INSTALLATION MODE 2.1. Precautions to be observed for the choice and installation of the device • Make sure that the protection level assured by the SAFEasy (Type 2) is compatible with the real danger level of the machine to be controlled, according to EN 954-1. -
Page 9: General Information On Device Positioning
SF2 Series Instruction Manual 2.2. General information on device positioning The device should be carefully positioned, in order to reach a very high protection standard. Access to the hazardous area must only be possible by passing through the protecting safety light beams. - Page 10 Instruction Manual SF2 Series In normal operating conditions, machine starting must not be possible while operators are inside the hazardous area. When the installation of the safety light curtain very near to the dangerous area is possible, a second light curtain must be mounted in a horizontal position in order to prevent any lateral access (as shown in Fig.
-
Page 11: Minimum Installation Distance
SF2 Series Instruction Manual 2.2.1. Minimum installation distance The safety device must be placed at a specific safety distance (Fig.5). This distance must ensure that the dangerous zone cannot be reached before the dangerous motion of the machine has been stopped by the ESPE. - Page 12 Instruction Manual SF2 Series Note: The value of K is: 2000 mm/s if the calculated value of S is ≤ 500 mm 1600 mm/s if the calculated value of S is > 500 mm When the dangerous area can be reached through the upper and lower sides of the machine, where devices with >40 mm resolution are...
-
Page 13: Minimum Distance From Reflecting Surfaces
SF2 Series Instruction Manual 2.2.2. Minimum distance from reflecting surfaces Reflecting surfaces placed near the SAFEasy light curtains (over, under or laterally) may cause passive reflections. These reflections can compromise the recognition of an object inside the controlled area (see Fig. 8). - Page 14 Instruction Manual SF2 Series It is thus important to position the safety light curtain according to the minimum distance from any reflecting surface. The minimum distance depends on: • Operating distance between emitter (TX) and receiver (RX); • Maximum opening angle of the light beam sent by the safety light curtain, in particular: •...
-
Page 15: Installation Of Several Adjacent Safety Light Curtains
SF2 Series Instruction Manual 2.2.3. Installation of several adjacent safety light curtains When several safety devices must be installed in adjacent areas, it’s necessary to prevent the interferences between the emitter of one device and the receiver of another. Fig.10 gives an example of possible interferences between different devices and two pertinent solutions. -
Page 16: Use Of Deviating Mirrors
Instruction Manual SF2 Series 2.2.4. Use of deviating mirrors The control of any dangerous area, with several but adjacent access sides, is possible using the linear version without integrated Muting sensors and well-positioned deviating mirrors. Fig.11 shows a possible solution to control three different access sides, using two mirrors placed at a 45°... -
Page 17: Mechanical Mounting
SF2 Series Instruction Manual 3. MECHANICAL MOUNTING The emitting (TX) and receiving (RX) units must be installed with the relevant sensitive surfaces facing each other. The connectors must be positioned on the same side and the distance must be included within the operating range of the SF2 light curtain (see section 9 “Technical data”). - Page 18 Instruction Manual SF2 Series L-brackets are available on request (see Fig.13). Rigid fixing brackets can be used where no large mechanical compensation is required during the alignment operation. The rotating supports for the correction of the bar inclination are available on request.
-
Page 19: Electrical Connections
SF2 Series Instruction Manual 4. ELECTRICAL CONNECTIONS Every electrical connection to the emitting and receiving unit is made through a male M12 connector, located in the lower part of the safety light curtain. A M12 5-pole connector is used for the receiver and a M12 4-pole connector for the emitter. -
Page 20: Notes On The Connections
Instruction Manual SF2 Series 4.1. Notes on the connections For the correct functioning of the SAFEasy safety light curtains, the following precautions regarding the electrical connections have to be respected: • Do not place connection cables in contact or near high-voltage cables (e.g. -
Page 21: Test Timing Diagrams
SF2 Series Instruction Manual 4.2. TEST timing diagrams The output functions are self-checked every 0.5 seconds during normal operation. The TEST function also can be activated by simply pressing the external push-button for at least 0.5 seconds as shown in the following timing diagram. - Page 22 Instruction Manual SF2 Series • The OSSD1 and OSSD2 safety contacts cannot be connected in series or in parallel, but can be used separately. • If one of these configurations (Fig.15, 16, 17) is erroneously used, the device enters into the block condition (see cap.7 “Diagnostic functions”).
- Page 23 SF2 Series Instruction Manual The following connection diagram shows how the SF2 light curtain can be connected with force-guided relays (MPCE). User-supplied fuse. For normal operation mode, the TEST wire has to be connected to 24 Vdc by a NC button. If the wire is not connected or connected to 0VDC, the SF2 light curtain enters in break condition.
-
Page 24: Alignment Procedures
Instruction Manual SF2 Series 5. ALIGNMENT PROCEDURES The alignment between the emitting and the receiving units is necessary to obtain the correct functioning of the light curtain. The alignment is perfect if the optic axes of the first and the last emitting unit’s beams coincide with the optic axes of the corresponding... - Page 25 SF2 Series Instruction Manual Verify that one of the following conditions is present on the RX unit: SAFE CONDITION 1. The green LED (SAFE) is ON and the red LED (BREAK) is OFF. Both yellow LEDs (High ALIGN and Low ALIGN) are OFF.
-
Page 26: Correct Alignment Procedure (Manual Restart)
Instruction Manual SF2 Series 5.2. Correct alignment procedure (MANUAL RESTART) OPERATING STATUS WAITING SAFE BREAK condition RESTART condition condition (BREAK) Yellow Yellow Green - Normal - Light - Non- - Non- Light operating curtain aligned aligned curtain mode, no aligned,... - Page 27 SF2 Series Instruction Manual BREAK CONDITION 2. The green LED (SAFE) is OFF and the red LED (BREAK) is ON. The status of the yellow LEDs (HIGH ALIGN, LOW ALIGN) is different from the WAITING FOR RESTART condition. Non- aligned light curtain condition.
-
Page 28: Restart Mode
Instruction Manual SF2 Series 6. RESTART MODE An opaque object detected by the beams causes the switching of the OSSD outputs (i.e. the opening of the safety contacts - BREAK condition). The restart of the ESPE (i.e. the closing of the OSSD safety contacts - SAFE condition) can be carried-out in two different ways: •... - Page 29 SF2 Series Instruction Manual The Fig.18 below shows the two functioning modes. BREAK SAFE AUTOMATIC RESTART VERSION NORMAL FUNCTIONING OSSD OFF OSSD ON FREE BEAMS INTERRUPTED FREE BEAMS BEAMS TEST push-button SAFE BREAK BREAK SAFE MANUAL RESTART VERSION OSSD ON...
-
Page 30: Diagnostic Functions
Instruction Manual SF2 Series 7. DIAGNOSTIC FUNCTIONS 7.1. Visualisation of the functions operator visualise operating condition of the light curtains through four LEDs positioned on the receiving unit and two LEDs on the emitting unit (Fig.19). SAFE/BREAK LED: • SAFE... -
Page 31: Fault Messages And Diagnostics
SF2 Series Instruction Manual 7.2. Fault messages and Diagnostics The operator is able to check the main causes of the system stop and failure, using the same LEDs used for the visualisation of the functions. RECEIVING UNIT: Failure Check and Repair - Check the output connections. -
Page 32: Checks And Periodical Maintenance
Instruction Manual SF2 Series 8. CHECKS AND PERIODICAL MAINTENANCE The following is a list of recommended check and maintenance operations that should be periodically carried-out by qualified personnel. Check that: • The ESPE stays locked during beam interruption along the entire protected area, using the suitable “Test Piece”. -
Page 33: General Information And Useful Data
SF2 Series Instruction Manual 8.2. General information and useful data The safety devices fulfil their safety function only if they are correctly installed, in accordance with the Standards in force. If you are not certain to have the expertise necessary to install the device in the correct way, DATASENSOR Technical Service is at your disposal to carry-out the installation. -
Page 34: Technical Data
Instruction Manual SF2 Series 9. TECHNICAL DATA Power supply = Vdd: 24 Vdc ± 20% (SELV/PELV) Emitter consumption (TX): 50 mA max / 1W Receiver consumption (RX): 90 mA max (without load) / 2.5 W Outputs: 2 PNP output; (2 NPN on request) Short-circuit protection max: 1.4A at 55 °C... -
Page 35: List Of The Available Models
SF2 Series Instruction Manual 10. LIST OF THE AVAILABLE MODELS Model Length of the Length of the Number Response Resolution Operating sensitive controlled time distance area (mm) area (mm) beams (msec) (mm) SF2-30-015- PP-* SF2-30-030- PP-* SF2-30-045- PP-* SF2-30-060- PP-* SF2-30-075- PP-* 0.2…15... -
Page 36: Dimensions
Instruction Manual SF2 Series 11. DIMENSIONS All the dimensions given are in mm. MODEL SF2-30-015- PP-* SF2-kk-030- PP-* SF2-kk-045- PP-* SF2-kk-060- PP-* SF2-kk-075- PP-* SF2-kk-090- PP-* SF2-kk-105- PP-* 1109 1029 SF2-kk-120- PP-* 1256 1176 SF2-kk-135- PP-* 1403 1323 SF2-kk-150- PP-*... -
Page 37: Accessories
SF2 Series Instruction Manual 12. ACCESSORIES Fixing brackets Also available: MODEL DESCRIPTION ST-KSF2 Antiscratch fixing bracket (kit 4 pcs) ST-KSTD Angled fixing bracket (kit 4 pcs) ST-K4AV Antivibration support (kit 4 pcs) ST-K6AV Antivibration support (kit 6 pcs) ST-K4OR Orientable support (kit 4 pcs) - Page 38 Instruction Manual SF2 Series Deviating mirrors MODELLO DESCRIZIONE (mm) (mm) SE-DM 500 Deviating mirror H= 550 mm SE-DM 600 Deviating mirror H= 700 mm SE-DM 800 Deviating mirror H= 900 mm SE-DM 900 Deviating mirror H= 1000 mm 1004 SE-DM 1200...
- Page 39 SF2 Series Instruction Manual Columns and floor stands L (mm) X (mm) MODEL DESCRIPTION SE-S 800 Column and floor stand H= 800 mm 30x30 SE-S 1000 Column and floor stand H= 1000 mm 1000 30x30 SE-S 1200 Column and floor stand H= 1200 mm...
- Page 40 Instruction Manual SF2 Series Protective stands sp.2 sm.50x45° N°4 Ø6.6 N°2 MODEL DESCRIPTION L (mm) SE-P 150 Protective stand H= 273 mm SE-P 300 Protective stand H= 420 mm SE-P 450 Protective stand H= 567 mm SE-P 600 Protective stand H= 714 mm...
- Page 41 CS-A1-03-G-05 Axial 5-pin 5 m cable CS-A1-03-G-10 Axial 5-pin 10 m cable Safety relay The drawing shows the connection between the SAFEasy safety light curtain series and and the Type 4 safety relay of the SE-SR2 series functioning in the automatic Restart mode (left side) and manual Restart with monitoring (right side).
