SMC Networks SV Series Manual

Serial wiring with input/output unit 5 port solenoid valve for ex250
Hide thumbs Also See for SV Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Information
Serial Wiring with Input/Output Unit
5 Port Solenoid Valve for EX250
SV/VQC
Series
Series
Applicable protocol
DeviceNet
PROFIBUS-DP
CC-Link
Serial wiring
with input/output
AS-i
unit
EX250
CANopen
ControlNet
EtherNet/IP
TM
DeviceNet
is a trademark of ODVA.
ControlNet
TM
is a trademark of ControlNet International.
TM
EtherNet/IP
is a trademark used under license by ODVA.
Applicable
manifold
TM
SV1000
2000
3000
VQC1000
TM
TM
SV
Series
EtherNet/IP ™ compatible products
are now available.
b Compatible with DHCP
b Communication speed: 10 M/100 Mbps
b Able to HOLD/CLEAR the output in case of
an error occurrence.
2000
4000
Series
Akihabara UDX 15F,
4-14-1, Sotokanda, Chiyoda-ku,
Tokyo 101-0021, JAPAN
URL http://www.smcworld.com
©2006 SMC Corporation
All Rights Reserved
06-E532 Issued: September, 2006
D-DNP
P-120 (DN)
VQC
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SV Series and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks SV Series

Summary of Contents for SMC Networks SV Series

  • Page 1 Akihabara UDX 15F, Information 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, JAPAN URL http://www.smcworld.com ©2006 SMC Corporation All Rights Reserved 06-E532 Issued: September, 2006 D-DNP P-120 (DN) Serial Wiring with Input/Output Unit 5 Port Solenoid Valve for EX250 SV/VQC Series Applicable EtherNet/IP ™ compatible products Series Applicable protocol manifold...

  • Page 2: How To Order

    EX250 Serial Wiring With Input/Output Unit Series For details about certified products conforming to international standards, visit us at www.smcworld.com. How to Order b Tie-rod Base SS5V W 10S1 05 U Series SV1000 Enclosure Input block stations SV2000 IP67 specification None Mounting SV3000...
  • Page 3 ∗ Built-in back pressure check valve type is applicable to the SV1000 • For solenoid valve specifications and dimensions, refer to the SV series in series only. the “Best Pneumatics 2004 Vol. 1” catalog. • For SI unit dimensions, refer to page 12.
  • Page 4 VQC1000 Series Base Mounted Plug-in Manifold For details about certified products conforming to international standards, visit us at www.smcworld.com. How to Order Manifold VV5QC 1 1 Option Series VQC1000 None With back pressure check valve (all stations) Note 2) With DIN rail (Rail length: Standard) Manifold D„...
  • Page 5 Series Plug-in Manifold How to Order Valves VQC 1 Series Manual override VQC1000 Nil: Non-locking push type With/Without light/surge (Tool required) voltage suppressor Type of actuation 2 position single 4 position dual 3 port valve Note) Rated voltage : Locking type (Tool required) P EB 24 VDC...
  • Page 6 VQC2000 Series Base Mounted Plug-in Manifold For details about certified products conforming to international standards, visit us at www.smcworld.com. How to Order Manifold C6 SDQ VV5QC 2 1 Option None Series Note 2) With back pressure check valve (all stations) VQC2000 With DIN rail (Rail length: Standard) D„...
  • Page 7 Series Plug-in Manifold How to Order Valves VQC 2 Series Manual override VQC2000 Nil: Non-locking push type With/Without light/surge (Tool required) voltage suppressor Type of actuation 2 position single 4 position dual 3 port valve Note) Rated voltage : Locking type P EB (Tool required) 24 VDC...
  • Page 8 VQC4000 Series Base Mounted Plug-in Manifold For details about certified products conforming to international standards, visit us at www.smcworld.com. How to Order Manifold VV5QC 4 1 16 03 Option Series None VQC4000 Special wiring specification Note) (Except double wiring) Manifold Note) Be sure to indicate the wiring specification in the specification sheet.
  • Page 9 Series Plug-in Manifold How to Order Valves VQC 4 1 0 Series Manual override VQC4000 Nil: Non-locking push type (Tool required) With/Without light/surge Type of actuation voltage suppressor 2 position single Without light, with surge voltage suppressor P EB 2 position double (Metal) : Locking type Rated voltage (Tool required)
  • Page 10 Serial Wiring with Input/Output Unit EX250 Series Integrated serial wiring • Ease of mounting, and space-savings are achievable, integrating wiring by connector. Input/Output number • Compatible with 32-digital outputs/inputs. Enclosure • IP67 compatible (IP40: compliant with ControlNet) How to Order SI Unit SI Unit EX250 S Input block...

  • Page 11: Maximum Transmission Distance

    EX250 Series Serial Wiring with Input/Output Unit SI Unit Specifications EX250-SDN1 EX250-SPR1 EX250-SMJ2 EX250-SCA1 EX250-SCN1 EX250-SEN1 EX250-SAS3/5 EX250-SAS7/9 Model Protocol DeviceNet PROFIBUS-DP CC-Link CANopen ControlNet EtherNet/IP AS-Interface (AS-i) Applicable CiA DS-301 Version 2.0 Version 2.11 system Note 1) Version Release 2.0 Ver.1.10 V4.02 and Errata 3...
  • Page 12 EX250 Series SI Unit Dimensions / Parts Description EX250-SDN1 EX250-SPR1 EX250-SMJ2 (DeviceNet) (PROFIBUS-DP) (CC-Link) Position indicator LED Position indicator LED Position indicator LED Switch protective cover PW(V) PWR(V) PWR(V) MOD/NET B RATE STATION NO. ADDRESS SETTINGS L RUN L ERR EX250 EX250 EX250...
  • Page 13 EX250 Series Serial Wiring with Input/Output Unit Specific Product Precautions Be sure to read this before handling. Please consult with SMC for applications outside the specifications. When one AS-i power supply system is used Caution EX250-SAS7 EX250-SAS9 Power supply voltage Note 1) Supplied from AS-i circuit, 26.5 to 31.6 VDC Note 1) For communication power supply, use a power supply...

  • Page 14: Input Block

    EX250 Series How to Order Input Block Input Block EX250 IE 1 Input block Output block Block type SI unit M12 connector, 2 inputs M12 connector, 4 inputs M8 connector, 4 inputs Power block Input block Output block SI unit For options, refer to page 16.
  • Page 15 EX250 Series Serial Wiring with Input/Output Unit Input Block Dimensions / Parts Description EX250-IE1, EX250-IE2 Note) Fuse NPN/PNP convertion switch Position Position indicator LED indicator LED EX250 EX250 EX250-IE1 EX250-IE2 +24 V Connector for Fuse input device connection (M12, 5 pins, socket) EX250-IE1 Connector’s pin assignment for the Circuit diagram:...

  • Page 16: Example Of Connections

    EX250 Series Options Example of connections Connection example of the SI unit Connection example of the SI unit compliant with DeviceNet compliant with EtherNet/IP t End plate (Input side) u Power block t End plate (Input side) y Output block y Output block SI unit SI unit...
  • Page 17 EX250 Series Serial Wiring with Input/Output Unit q Communication connector For DeviceNet type SI unit EX500 AC Cable length (l) 1000 [mm] 5000 [mm] 40.7 Terminal no. Core wire colors : DRAIN Red: V+ Black: V– White: CAN H Blue: CAN L Socket connector Connections pin arrangement...
  • Page 18 EX250 Series Options w Power cable with connector (for SI unit) For PROFIBUS-DP, EtherNet/IP type SI unit EX500 AP Cable length (l) 1000 [mm] 5000 [mm] Terminal no. Core wire colors Brown: 0 V (Solenoid valve power supply) White: 24 VDC +10%/–5% (Solenoid valve power supply) Blue: 0 V (Input and control power supply) Black: 24 VDC 10% (Input and control power supply) Gray: PE...
  • Page 19 EX250 Series Serial Wiring with Input/Output Unit r Replacement fuse Replacement fuse required when the fuse for the input block (EX250-IE„) overcurrent protection is blown. EX9 FU05 Fuse Model EX9-FU05 Applicable model EX250-IE„ Rated current 0.5 A Rated insulation capacity 48 VAC/DC 50 A Fuse resistance value 0.36...
  • Page 20 EX250 Series Options y Output block / u Power block Output block Power block Features: • Able to retrofit to the valve manifold, using the unused points. • 2-output (M12 connector) • + common / – common are standardized. • Able to drive by 0.5 A per point. Input block Output block Input block...
  • Page 21 EX250 Series Serial Wiring with Input/Output Unit Output Block Specifications Model EX9-OET1 EX9-OET2 EX9-OEP1 EX9-OEP2 M12 connector (5 pins) Output connector Internal current consumption 40 mA or less PNP output (–COM.) NPN output (+COM.) PNP output (–COM.) NPN output (+COM.) Output type Number of outputs 2 points...

  • Page 22: Circuit Diagram

    EX250 Series Options Output Block Dimension Power Block Dimension Position indicator LED Position indicator LED Power supply connecor 21.2 21.2 Connector for (M12, 5 pins, socket) output device connection 59.8 59.8 (M12, 5 pins, socket) Power supply input connector (M12, 5 pins, plug) 26.7 26.7 Circuit Diagram...
  • Page 23 EX250 Series Serial Wiring with Input/Output Unit i Cable with connector for output entry EX9 AC Cable length (l) Terminal no. Core wire colors 1000 [mm] 3000 [mm] Brown White Blue Black Gray Plug connector Connections pin arrangement Note) Wiring to the output devices differs depending on the output style of the output block. For details, please refer to the technical documentation for the output block.
  • Page 24 EX250 Series Options !0 AS-i power cable Cable connecting between AS-i power supply line (for external devices) branch connector (M12) and the power block’s power supply input connector. EX9 AC 48.1 Cable length (l) 1000 [mm] 3000 [mm] 5000 [mm] Terminal no.

  • Page 25: Parts List

    EX250 Series Serial Wiring with Input/Output Unit How to Increase Input/Output Blocks, Procedure Drawing Parts List Description Part no. Note EX250-S„ SI unit For details, refer to page 10. Input block (M12, 2 inputs) EX250-IE1 PNP/NPN switchable EX250-IE3 Input block (M8, 4 inputs) PNP/NPN switchable End plate (Input side) EX250-EA1...
