ATX SignalOn N-M 18M0 Series Installation And Operation Manual

Rf passive modules

Advertisement

Quick Links

SignalOn
Series
®
D3.1/CCAP
1.2 GHz
Compliant
RF Passive Modules
INSTALLATION & OPERATION MANUAL
www.atx.com
www.atxnetworks.com
ATX Confi dential & Proprietary

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SignalOn N-M 18M0 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ATX SignalOn N-M 18M0 Series

  • Page 1 SignalOn Series ® D3.1/CCAP ™ 1.2 GHz Compliant RF Passive Modules INSTALLATION & OPERATION MANUAL www.atx.com www.atxnetworks.com ATX Confi dential & Proprietary...
  • Page 2 ® service mark of ATX in the United States and/or other countries. Products or features contained herein may be covered by one or more U.S. or foreign patents. Other non-ATX product and company names in this manual are the property of their respective companies.
  • Page 3: Table Of Contents

    MAINTENANCE ............................5-1 5.1. Preventive Maintenance ........................5-1 SPECIFICATIONS ............................. 6-1 SERVICE & SUPPORT ..........................7-1 7.1. Contact ATX Networks ........................7-1 7.2. Warranty Information ......................... 7-1 7.3. Safety ..............................7-1 SignalOn Series – RF Passive Modules - Installation & Operation Manual ®...
  • Page 4 Make-Before-Break (MBB) Splitter/Combiner Module ...........2-1 Plain Splitter/Combiner Module ................2-2 Combining 16 Input Signals ...................4-1 Distributing Signals ....................4-2 Tables Make-Before-Break (MBB) Splitter/Combiner Module Specifications....6-1 Plain Splitter/Combiner Module Specifications ............6-1 SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 5: About This Manual

    The following listing is a bibliography of applicable ANSI and Bellcore documents: MIL-STD-202 Test Methods for Electronic and Electrical Component Parts UL 60950 Safety, Telephone Equipment SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confi dential & Proprietary...
  • Page 6: List Of Acronyms And Abbreviations

    American Wire Gauge ANSI American National Standards Institute Customer Premise Equipment Customer Interface Federal Communications Commission Ground Make-Before-Break Monitor Network Interface Device Receive Transmit SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 7: General Description

    3. Position new pad in the module and press straight into place. 4. Replace protective cover on the front of the module and hand-tighten the thumbscrew. SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 8: Diplex Filter Module

    A simplified Condition and Monitor schematic is shown in Figure 2. INPUT OUTPUT -20 dB Figure #2: Condition and Monitor Module Schematic SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 9: Functional Description

    0 dB 0 dB DEFAULT DEFAULT DEFAULT DETAIL (TYP 8) DETAIL (TYP 8) DETAIL (TYP 6) N-MC*18M0* N-MC*24M0* N-MC*32M0* Figure #3: Make-Before_Break (MBB) Splitter/Combiner Module SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 10: Plain Splitter/Combiner Module

    Plain Triple 2-way Splitter/ PORT Combiner Plain Dual 4-way Splitter/ Combiner PORT N-MP*18* PORT PORT PORT N-MP*32* PORT N-MP*24* Figure #4: Plain Splitter/Combiner Module SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 11: Planning

    • Allow sufficient room for cable management behind the chassis. Also leave sufficient vertical and horizontal cable pathways above and below the chassis. SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 12 CHAPTER 3: PLANNING This page left intentionally blank. SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confi dential & Proprietary...
  • Page 13: Operation

    PROCESSOR 8 x 1 SIGNAL PROCESSOR 2 x 1 DISTRIBUTION NETWORK SIGNAL PROCESSOR 8 x 1 SIGNAL PROCESSOR Figure #5: Combining 16 Input Signals SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 14: Distributing Signals

    LASER XMIT NODE 4 x 1 LASER XMIT NODE COMBINING 2 x 1 NETWORK TO OTHER LASER 4 x 1 TRANSMITTERS Figure #6: Distributing Signals SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 15: Maintenance

    5.1. Preventive Maintenance NOTE: There are no customer serviceable parts in any of the components in this system; return all failed components to ATX Networks for service or repair. Opening the module voids all applicable warranties. The outside of the chassis and passive components should be cleaned during routine office equipment maintenance. Care must be taken to prevent dust and dirt from getting into any of the coaxial jacks or connectors.
  • Page 16 CHAPTER 5: MAINTENANCE This page left intentionally blank. SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confi dential & Proprietary...
  • Page 17: Specifications

    < 0.5 5-50 MHz RETURN LOSS 50-1002 MHz 1002-1218 MHz NOTE: * = F or B (BNC) connectors. Table #2: Plain Splitter/Combiner Module Specifications SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 18 CHAPTER 6: SPECIFICATIONS SignalOn Series – RF Passive Modules - Installation & Operation Manual ® ATX Confidential & Proprietary...
  • Page 19: Service & Support

    Please contact ATX Technical Support for assistance with any ATX products. Please contact ATX to obtain a valid RMA number for any ATX products that require service and are in or out-of-warranty before returning a failed module to ATX. TECHNICAL SUPPORT Tel: 289.204.7800 –...
  • Page 20 9001:15 REGISTERED ATX Networks © 2020 by ATX Networks Corp. and its affiliates (collectively “ATX Networks Corp.”). Tel: 289.204.7800 | Toll-Free: 866.YOUR.ATX (866.968.7289) | support@atx.com All rights reserved. This material may not be published, broadcast, rewritten, or redistributed. Information in this document is subject to change without notice.
