- Page 1 ChromaFlex ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module HARDWARE INTERFACE MANUAL www.atxnetworks.com www.atxnetworks.com...
- Page 2 Specifications subject to change without notice. Products or features contained herein may be covered by one or more U.S. or foreign patents. DOCSIS and other non-ATX product and company names in this manual are the property of their ® respective companies.
-
Page 3: Table Of Contents
Contact ATX Networks ........ - Page 4 This page intentionally left blank. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 5: Important Safety Instructions
Route all power cords so that people cannot walk on, place objects on, or lean objects against them. • Make sure the mounting surface or rack is stable and can support the size and weight of this equipment. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... -
Page 6: Power Connections
Always use a fuse of the correct type and rating. The correct type and rating are indicated on this equipment. 1 .7 Laser Safety This equipment may contain or be connected to an infrared laser source that transmits intensity-modulated light and emits invisible radiation. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... -
Page 7: Laser Power & Warning Labels
This equipment may contain or be connected to other equipment containing Class 1M laser sources. The following labels adhered to each product will indicate the type of laser source utilized along with general laser radiation labels. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... - Page 8 CHAPTER 2: IMPORTANT SAFETY INSTRUCTIONS This page intentionally left blank. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 9: Product Introduction
DMT44 has four separate lasers with one unique (narrowcast) port per laser. For a total of four RF inputs at rear of chassis. Any Broadcast/Narrowcast combining is done externally if needed. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... - Page 10 CHAPTER 2: PRODUCT INTRODUCTION This page intentionally left blank. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 11: Unpacking & Inspecting A New Unit
UNPACKING & INSPECTING A NEW UNIT Unpacking & Inspecting a New Unit Before shipment, ATX inspects and packs all the essential items carefully. Nevertheless, damage may occur during shipment. The carrier assumes full responsibility for a safe delivery of the equipment. - Page 12 CHAPTER 3: UNPACKING & INSPECTING A NEW UNIT This page intentionally left blank. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 13: Specifications
CHAPTER 4: SPECIFICATIONS SPECIFICATIONS Specifications See ChromaFlex DMT24, DMT34 & DMT44 DWDM Transmitter Specs & Ordering Info pdf at atxnetworks.com ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... - Page 14 CHAPTER 4: SPECIFICATIONS This page intentionally left blank. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 15: Block Diagram & Operation
ITU* RF Det. Variable (*-3) OUT 3 Attenuator ITU* RF Det. * = card DMT34 number (1..8) Figure 2: ChromaFlex DMT34 Transmitter Module Block Diagram ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... - Page 16 An internal multiplexer option is available in which case each wavelength is multiplexed internally with the combined wavelengths connected to output port 1. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 17: Front Panel
Red = Major Alarm, RF Out of Range +/- 3 dB For more information regarding alarm status and monitoring refer to the ChromaFlex Operation Manual. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... - Page 18 CHAPTER 6: FRONT PANEL This page intentionally left blank. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 19: Module Installation
The module LEDs should now be lit with the four OPT LEDs green and the four RF LEDs red (DMT44) if RF has not already been connected to the chassis rear panel RF connectors. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... - Page 20 CHAPTER 7: MODULE INSTALLATION This page intentionally left blank. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 21: Module Connections
1-1 is connected to chassis slot 1- laser transmitter 1 within the module. RF connector 1-2 is connected to chassis slot 1- laser transmitter 2 within the module. Figure 6: DMT24 – Rear Panel RF Connections Figure 7: DMT34 – Rear Panel RF Connections ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... -
Page 22: Optical Connections
1. Your specific design may include additional components such as external multiplexers, an EDFA, return path receivers, destacker modules or other external components. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... - Page 23 Connect each output port (1 through 4) to a fi ber jumper utilizing a good quality clean LC/APC connector to the next device or fi ber cable per your specifi c design schematic drawing. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
- Page 24 CHAPTER 8: MODULE CONNECTIONS This page intentionally left blank. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 25: Module Set-Up
The following DMTx4 Hand-held Display menu tree will assist in navigating the Hand-held Display. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... -
Page 26: Agc Mode (Hand-Held Display)
Using the Hand-held Display choose the appropriate slot for the desired module location. Example DMT34 - With a combined Broadcast/Narrowcast total RF power of 31 dBmV plug the Broadcast cable into ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... -
Page 27: Mgc Mode (Hand-Held Display)
The Att (dB) value should be +3.5 ± 0.5 dB with a total combined input power of 31 dBmV at the back of the chassis. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... -
Page 28: Setting Transmitter Fiber Length
Enter the fiber length in km associated with the selected laser transmitter. This should not be based on distance measured on a map. Use an optical TDR for proper fiber length. Repeat for each laser transmitter. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual... -
Page 29: Troubleshooting The Dmtx4
Communication Issue with Unit Please confirm set-up is as described in the User Interface document. If problem persists, please contact customer service for further help. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual 10-1... - Page 30 CHAPTER 10: TROUBLESHOOTING THE DMTX4 This page intentionally left blank. 10-2 ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual...
-
Page 31: Service & Support
(408) 227-3403 Email: opticalsales@atxnetworks.com Web: www.atxnetworks.com 11 .2 Warranty Information All of ATX Networks’ products have a 1-year warranty that covers manufacturer’s defects or failures. ChromaFlex DMT24, DMT34 & DMT44 Multi-Wavelength DWDM Direct Modulated Transmitter Module – Hardware Interface Manual 11-1... - Page 32 9001:15 REGISTERED ATX Networks © 2018 ATX Networks 1-501 Clements Road West, Ajax, ON L1S 7H4 Canada Information in this document is subject to change without notice. Tel: 905.428.6068 | Toll Free: 800.565.7488 | support@atxnetworks.com Rev. 09/18 (ANW1169) www.atxnetworks.com...
