Klipsch RSB-11 Firmware Update Instructions

RSB-11
SOUNDBAR FIRMWARE UPDATE INSTRUCTIONS
These instructions apply to RSB-11 Soundbars with the Serial
Numbers 1063117164500001 and above
Copy the "rsb11.hex" file and the "csr11b.ybin" file
1
to an empty USB flash drive.
Insert the USB drive into the USB port on the rear
3
of the Soundbar.
The Dolby Digital LED will light up when the MCU
5
firmware update has started and you can release
the Vol+ key.
Unplug the power cord from the Soundbar.
2
Soundbar
Press and hold the Vol+ key on the Soundbar,
4
then plug in the power cord
(while still holdingthe Vol+ key).
HDMI 1 HDMI 2 HDMI 3 TV
As the update installs - the Virtual Surround Mode
6
LED will light up, then the Dialog LED, then the
Night Mode LED. All LED's will turn off when the
update is complete and the unit will power down.
DIALOG NIGHT
