Rear View; Bottom View - Lenovo ThinkPad S5 2nd Generation Hardware Maintenance Manual

Hide thumbs

Advertisement

Table of Contents

Rear view

1
ac power connector
3
High-Definition Multimedia Interface (HDMI™)
connector
5
Always On USB 3.0 connector
7
System-status indicator
1
: For the description of the system-status indicator, see Chapter 5 "Status indicators" on page 43.

Bottom view

1
Emergency-reset hole
3
Built-in battery
5
Internal storage drive
48
Hardware Maintenance Manual
1
2
Fan louvers
4
Ethernet connector
6
Audio connector
2
M.2 solid-state drive
4
Base cover assembly
6
Memory-upgrade slots
