D
S
ean
toves
Dean Forge Fabrication Ltd. Dean Prior, Buckfastleigh, Devon TQ11 0LS
T e l: 0 1 3 6 4 6 4 3 5 7 4
w w w.d e a n–f o r g e.c o.u k
e m a i l: s t o v e s @ d e a n-f o r g e.c o.u k
Operating Instructions for The Dean Forge Dartmoor 5E and W5E
Stoves
Including Huccaby and Foxworthy
st
DM5/W5E issue 1. 21
October 2019
All stoves meet the essential type test requirement BS EN13240:2001 +
A 2:2004
The Clean Air Act 1993 and Smoke Control Areas
Under the Clean Air Act local authorities may declare the whole or part of the district of the authority
to be a smoke control area. It is an offence to emit smoke from a chimney of a building, from a
furnace or from any fixed boiler if located in a designated smoke control area. It is also an offence to
acquire an "unauthorised fuel" for use within a smoke control area unless it is used in an "exempt"
appliance ("exempted" from the controls which generally apply in the smoke control area).
The Secretary of State for Environment, Food and Rural Affairs has powers under the Act to
authorise smokeless fuels or exempt appliances for use in smoke control areas in England. In
Scotland and Wales this power rests with Ministers in the devolved administrations for those
countries. Separate legislation, the Clean Air (Northern Ireland) Order 1981, applies in Northern
Ireland. Therefore it is a requirement that fuels burnt or obtained for use in smoke control areas have
been "authorised" in Regulations and that appliances used to burn solid fuel in those areas (other
than "authorised" fuels) have been exempted by an Order made and signed by the Secretary of State
or Minister in the devolved administrations.
The Dean Stoves, Dartmoor 5 Eco, Foxworthy 5 Eco, Dartmoor W5 Eco and Huccaby W5 Eco has
been recommended as suitable for use in smoke control areas when burning wood logs.
The Dean Stoves Dartmoor 5 Eco, Foxworthy 5 Eco, Dartmoor W5 Eco and Huccaby W5 Eco is
factory fitted with a permanent stop to prevent closure of the secondary air control for use in a smoke
controlled area.
Further information on the requirements of the Clean Air Act can be found here:
http://smokecontrol.defra.gov.uk/
Your local authority is responsible for implementing the Clean Air Act 1993 including designation and
supervision of smoke control areas and you can contact them for details of Clean Air Act
requirements
Page 1 of 18
Advertisement
Table of Contents
Related Manuals for Dean Forge Dartmoor 5E
Summary of Contents for Dean Forge Dartmoor 5E
- Page 1 @ d e a n-f o r g e.c o.u k Operating Instructions for The Dean Forge Dartmoor 5E and W5E Stoves Including Huccaby and Foxworthy DM5/W5E issue 1.
-
Page 2: Safety Note
Please Note. The Huccaby is a variant of the Dartmoor W5 and share the same fire box. The Foxworthy is a variant of the Dartmoor 5 and shares the same fire box. Please refer to the Dartmoor W5 instructions for the Huccaby and the Dartmoor 5 instructions for the Foxworthy stoves unless specific points about these models are mentioned within the instructions. - Page 3 Door Operation & controls The door handle and air controls can become very hot so use the glove provided. Tools are provided to control the spin wheel, air wash lever and the tertiary air slider. Controlling the stove Primary air control A is spin wheel on the door The primary air control is a spin wheel on the door, this control is used for lighting the fire or boosting the fire this also is the main control when burning solid fuel when a multi-fuel kit in fitted.
- Page 4 When the fire has fully established and the logs are burning well, “this is usually about 10 to 20 minutes,” shut the primary air control and control the fire with the secondary air wash lever. If you are unable to sustain the fire with secondary control it is very likely that your logs have a high moisture content.
- Page 5 .Please Note: On lighting the stove for the first time from new the paint on the stove will cure and give off a metallic smell. It is advisable to ventilate the room i.e. open the windows in that area. This will subside after the stove has been burning hot for about 1 hour.
-
Page 6: Fault Finding
• Check the chimney breast in other rooms for signs of excessive heat and move objects away if necessary • At all times consider the safety of yourself and others in taking the above action Fitting Instructions for The Dean Forge Dartmoor 5 Eco and W5 Eco Stove (Including the Huccaby and Foxworthy) Unpacking Stove Remove all the polystyrene transit blocks holding the baffles. - Page 7 Chimney The Dartmoor 5 and W5 models require a 125mm (5”) first length of flue then stepping up into a minimum of 150mm (6”) liner. When using this stove with the smoke exempt air stop fitted the flue liner can be reduced to 125mm (5”). We strongly advise a minimum diameter of 150mm (6”) flue liner be fitted when possible.
- Page 8 Corner installation from Rear and side wall installation combustible walls from combustible walls Spigot Shield The minimum distances to combustible materials have been tested and approved when a spigot shield is fitted to the top of the heat shield. The spigot shield must be fitted to achieve these distances. The spigot shield “which is in the glove pack”...
- Page 9 Flue Connections and Outlets Flue Connections and Outlets Dean Stoves can be flued from the top and the back, or with a vertical back box. Horizontal flue from back of stove should not exceed 150mm. Diagrams showing the flue outlet from the top (A), back (B) and back box (C) All flue connections must be sealed with fire cement.
-
Page 10: Air Vent
Stove Performance Appliance Dartmoor 5 Eco Dartmoor W5 Foxworthy Eco Huccaby Dartmoor Baker 5 Eco Dartmoor W5 Baker Eco Fuel Wood Wood Total Efficiency 82.1 80.7 83.1 79.7 Nominal heat output 5..0 Mean CO emission (at 13 % O 0.08 0.12 0.11 0.08... - Page 11 Installing a Multi-fuel kit in a Dartmoor 5 Eco To install a multi-fuel kit into a Dartmoor 5 woodburner first remove the inner side bricks by lifting the baffle plate up on one side above the side brick then slide the side brick out being careful not to damage it.
- Page 12 Installing a Multi-fuel kit in a Dartmoor W5 Eco To install a multi-fuel kit into a Dartmoor W5 woodburner first remove the inner side bricks by lifting the baffle plate up on one side above the side brick then slide the side brick out being careful not to damage it.
-
Page 13: Ec Declaration Of Conformity
EC Declaration of Conformity The Undersigned, representing the following: Manufacturer Dean Forge Ltd Dean Prior, Buckfastleigh, Devon, TQ11 0LS Herewith declare that the products: Description Product Code Dartmoor 5 STDFEDA5 Dartmoor W5 STDFEDAW5 Huccaby STDFEHU Foxworthy STDFEFO Description of product: Dartmoor wood and multifuel heating stove product range. - Page 14 Provisions to which the product conforms: Product: Roomheater fired by solid fuel as covered under the scope of the standards listed. Intended use: Space heating in residential building. Characteristic Performance Report Fire Safety Satisfies Dartmoor 5- STDFDA5E/ STDFFOHE/ STDFFOLE Co @ 13% 0² Wood 0.08% Ancit 0.12% 5Kw @ 82.1% Wood -5Kw @ 80.7% Ancit Dartmoor W5- STDFDAW5E/ STDFHUE co@ 13% 0²...
- Page 15 Product Fiche according to Commission Delegated Regulation (EU)2015/1187 Energy Labelling of Local Space Heaters Supplier's Name Dean Stoves Model Dartmoor W5 Eco Energy Efficiency Class Nominal Heat Output to Room (KW) Nominal Heat Output to Water (KW) Seasonal Space Efficiency (%) 73.1 Net Efficiency (%) 83.1...
- Page 16 THE DEAN FORGE FABRICATION LTD STOVES GUARANTEE Dean Forge Fabrication Ltd offers a five-year guarantee which covers the main body of the stove for manufacturing defects. In the event of a manufacturing defect we will replace any defective part free of charge, labour cost excluded.
- Page 17 Page 17 of 18...
- Page 18 Dean Forge Fabrications Ltd Dean Prior Buckfastleigh Devon TQ11 0LS PRODUCT REGISTRATION Name ......................Address ...............................................................................Phone Number: ..........Suppliers Details: Name ......................Address ...............................................................................Phone Number: ..........Installers Details: Name ......................Address ......................................................................
