Dean Forge Fabrication Ltd. Dean Prior, Buckfastleigh, Devon TQ11 0LS
T e l:
0 1 3 6 4 6 4 3 5 7 4
w w w.d e a n–f o r g e.c o.u k
e m a i l: s t o v e s @ d e a n-f o r g e.c o.u k
Operating Instructions for the Dean Forge Clearburn Range
(Excluding Junior and Junior SE)
All stoves meet the essential type test requirement BS
EN13240:2001 + Amd 2:2004, CE marked
Unpacking Stove
The baffle plate will be found on the base of the stove and will need to be positioned as per
diagram. Check position of bricks. The secondary air control knob will be found inside the
stove stored with a glove and these instructions and will need screwing on.
Safety Note
Warning- The external parts of the appliance will get very hot to the touch and due care will
be needed when operating.
All stoves before being operated must be checked that the installation complies with all local,
national and European standards.
Before the stove is first used or when fitting other appliances into the room, please check that
adequate air vents are in place to cover the requirements of such appliances.
Extractor Fans. When operating an extractor fan in the same room or space as the appliance
the extractor fan could cause the stove not to function properly and pull dangerous fume into
the room. This must be checked by a trained qualified engineer before using the stove
Wood & Suitable fuels
Dry wood, 18% moisture content or below must be used or the stove and flue will tar up
and the door won't stay clean.
Wood is best seasoned by splitting it into a log and dried for 2 years in a covered area allowing
air to pass through. Peat can also be used but must be dry.
1
Advertisement
Table of Contents
Related Manuals for Dean Forge Croft Clearburn Junior
Summary of Contents for Dean Forge Croft Clearburn Junior
- Page 1 Dean Forge Fabrication Ltd. Dean Prior, Buckfastleigh, Devon TQ11 0LS T e l: 0 1 3 6 4 6 4 3 5 7 4 w w w.d e a n–f o r g e.c o.u k e m a i l: s t o v e s @ d e a n-f o r g e.c o.u k...
-
Page 2: Door Operation
When used as a Multi Fuel, use only smokeless fuels recommended for enclosed appliances. Please Note: Appliances should not be used as general incinerators or with non-recommended fuels. At no time should liquid accelerants I.e: Paraffin, Petrol, BBQ lighting liquid Etc be used. The chimney needs to be swept at least once a year. - Page 3 Lighting The Stove when using Wood Lay a fire of sticks and paper. Firelighters can be used if necessary. Check the secondary air lever is fully open and the primary air vents partially open. Light the fire and as the fire catches the paper you may then fully open the primary air vents.
-
Page 4: Pre-Season Check
Lighting The Stove When using Solid Fuel Lay a fire of sticks and paper, establish fire and then add the appropriate smokeless fuel and use the primary air control as the main control. If using a mixture of wood and coal, balance the primary and secondary control to achieve the desired fire. - Page 5 Notes Down draughts In adverse weather conditions down a draught may occur this could make the stove smoke, if this should happen shut all the stove air controls. If this occurs on a regular basis call in your engineer. It is possible a chimney cowl could cure this problem. Air vents Check periodically that the exterior ventilation grill is clear.
-
Page 6: Health And Safety Precautions
Stoves Introduction The Dean Forge Clearburn range of stoves has evolved and has been continuously updated for the last 37 years. These stoves have a robust fully welded carcass with a cast iron double glazed door. These stoves have a ceramic brick lining incorporating a preheated air wash system with 3 outlet options- top, back and back box. - Page 7 Chimney All croft clearburn stoves must have a minimum chimney height of 4m measuring from the stove outlet, the chimney must not be less than 150mm (6”) internal diameter. These stoves are not suitable to be used in a flue-shared situation. The chimney must be sound and of not too large a section.
-
Page 8: Register Plates
Table of distances from combustibles Stove Type Minimum from back of Minimum from side of appliance to combustibles appliance to combustibles Croft Clearburn Slimline 850mm 700mm Croft Clearburn Small 850mm 700mm Croft Clearburn Medium 1000mm 700mm Croft Clearburn Large 1200mm 800mm Croft Clearburn Small 850mm... - Page 9 Flue Connections and Outlets Dean Croft Clearburn stoves can be flued from the top and the back, or with a vertical back box. Horizontal flue from back of stove should not exceed 150mm. All flue connections must be sealed with fire cement. Doors in the register plate must be present or a soot box fitted in the back or side of the fireplace to enable access to clean the chimney when the stove is installed without a liner.
-
Page 10: Data Plate
Pre – Lighting Check and Commissioning Check all Building Regulations have been adhered to. The baffle plate is in the right position. A smoke test has been done to check the chimney is clear. Data Plate All stoves are numbered and performance marked on a data plate which is found on a swinging arm located under the stove. - Page 11 Multi fuel kit fitting instructions for Croft Slimline & Small This M/F kit consists of five parts: A. Centre Grate B. Main Grate C. Riddle bar D. Knob for riddle bar E. Ash pan tool F. Ash Pan To fit: Remove the front panel under the door and the log retainer.
- Page 12 Croft Clearburn Med & Large The M/F kit consists of six parts: A. Front plate with slides B. Grate frame C. Grate D. Ash pan E. Side panel F. Ash pan & front plate tool. To fit: Remove the blank plate under the door and log retainer. Fit grate frame between the bars welded in the bottom of the firebox with the front solid bar of the frame faced forward.
- Page 13 Table of mean flue temperatures with closed doors Stove Type Flue gas temp down stream of spigot, closed doors. Croft Clearburn Slimline 248C Croft Clearburn Small 317C Croft Clearburn Medium 348C Croft Clearburn Large 340C Croft Clearburn Small with log 317C store Flue Gas Mass Flow...
-
Page 14: Ec Declaration Of Conformity
Dean Forge Ltd Dean Prior, Buckfastleigh, Devon, TQ11 0LS Herewith declare that the products: Description Product Code Croft Clearburn Junior STDFCRJL, STDFCRJ Croft Clearburn Junior Inset STDFCRJIN Junior 105 SE STDFJ105L, STDFJ105H, STDFJ105HWD Croft Clearburn Slimline 5 SE STDFCRSL5 Croft Slimline 6... - Page 15 STDFCRJ 6348-01 Co @ 13% 0² Wood 0.31% Ancit 0.34% 5Kw @ 83% Wood – 5Kw @ 66.2% Ancit Emission of combustible Croft Clearburn Junior Inset- STDFCRJIN products and Thermal Co @ 13% 0² Wood 0.35% Ancit 0.40% 6700-1 output/Efficiency 5Kw @ 80.3% Wood -4.7Kw @ 73.2% Ancit...
- Page 16 THE DEAN FORGE FABRICATION LTD STOVES GUARANTEE Dean Forge Fabrication Ltd offers a five year guarantee which covers the main body of the stove for manufacturing defects. In the event of any failure we will replace any defective part free of charge, labour cost excluded.
- Page 18 Dean Forge Fabrication Ltd Dean Prior Buckfastleigh Devon TQ11 0LS PRODUCT REGISTRATION Name ......................Address ...............................................................................Phone Number: ..........Suppliers Details: Name ......................Address ...............................................................................Phone Number: ..........Installers Details: Name ......................Address ......................................................................
