Dean Forge Fabrication Ltd. Dean Prior, Buckfastleigh, Devon TQ11 0LS
T e l: 0 1 3 6 4 6 4 3 5 7 4
w w w.d e a n–f o r g e.c o.u k
e m a i l: s t o v e s @ d e a n-f o r g e.c o.u k
Operating Instructions for The Dean Forge Dartmoor Baker 8 Stove
DBM8 issue 1. July 2015
All stoves meet the essential type test requirement BS EN13240:2001 +
A 2:2004
Safety Note
Warning- The external parts of the appliance will get very hot to the touch and due care will be needed
when operating.
All stoves before being operated must be checked that the installation complies with all local, national
and European standards.
Before the stove is first used or when fitting other appliances into the room, please check that adequate
air vents are in place to cover the requirements of such appliances.
Extractor fans. When operating an extractor fan in the same room or space as the appliance the
extractor fan could cause the stove not to function properly and pull dangerous fumes into the room.
This must be checked by a trained qualified engineer before using the stove.
Wood & Suitable fuels
Dry wood, 18% moisture content or below must be used or the stove and flue will tar up and the
door won't stay clean.
Wood is best seasoned by splitting it into a log and drying it out for 2 years in a covered area so the air
can pass through to dry it out. Peat can also be used but must be dry.
Maximum Log Length
Maximum Log Diameter
400mm
100mm
When used as a Multi Fuel use only smokeless fuels recommended for enclosed appliances.
Please Note: Appliances should not be used as general incinerators or with non-recommended fuels.
At no time should liquid accelerants I.e.: Paraffin, Petrol, BBQ lighting liquid Etc be used.
Door Operation & controls
The door handle can become very hot so use the glove provided. A tool is provided to control the spin
wheel and air wash lever.
1
Advertisement
Related Manuals for Dean Forge Dartmoor Baker 8
Summary of Contents for Dean Forge Dartmoor Baker 8
- Page 1 @ d e a n-f o r g e.c o.u k Operating Instructions for The Dean Forge Dartmoor Baker 8 Stove DBM8 issue 1. July 2015...
- Page 2 Controlling the stove Primary air controls –A spin wheel on the door The primary air control is a spin wheel on the door This control is used for lighting the fire or boosting the fire This is the main control when burning Solid Fuel. Secondary air- B control leaver is situated on the right hand side near the top of the stove.
- Page 3 When refuelling the fire, to ensure clean burning, the primary air control should be opened for a couple of minutes so that flames are established on the newly fuelled logs. The primary air should be closed once these flames are fully established and the logs have become blackened. After refuelling, it is recommended that you do not leave the appliance unattended until it is certain that the logs are burning well with a sustained flame.
- Page 4 Please Note: On lighting the stove for the first time from new the paint on the stove will cure and give off a metallic smell. It is advisable to ventilate the room i.e. open the windows. This will subside fairly quickly after the stove has been burning hot for at least 2 hours.
-
Page 5: Fault Finding
Down draughts In adverse weather conditions a down draught may occur and will make the stove smoke, if this should happen shut all the stove air controls. If this occurs on a regular basis call in your engineer. It is possible a chimney cowl could cure this problem. Refuelling When refuelling, the primary air control should be opened for a couple of minutes so that flames are established on the newly fuelled logs. - Page 6 These fitting and operating instructions cover the Dartmoor 8 Stoves. Introduction The Dean Forge range of stoves has been continuously updated for over 37 years. These stoves have a robust fully welded carcass with a cast iron door. This stove has sacrificial insulated bricks and steel baffle plate and incorporates an air wash system with 3 outlet options- Top, Rear or Vertical Back box outlets of 150mm (6”).
- Page 7 Dean Forge Dartmoor Baker 8 Wood Burning 8kW nominal 74.9% Net Efficiency Dean Forge Dartmoor Baker 8 Solid Fuel (Ancit) 8kW nominal 73.0% Net Efficiency All stoves are tested to nominal outputs and will often well exceed these kilowatt ratings.
- Page 8 Stove Types Flue gas mass flow (gs) Dean Forge Dartmoor Baker 8 Wood Burning Dean Forge Dartmoor Baker 8 Solid Fuel (Ancit) Pre – Lighting Check and Commissioning Check all Building Regulations have been adhered to. The baffle plate is in the right position.
- Page 9 Multi fuel kit fitting instructions Fitting of M/F kit for Dean Forge Baker Dartmoor 8 Dean Forge Dartmoor 8 Baker Multi Fuel Parts This M/F kit consists of Three parts A.
- Page 10 Dean Forge Dartmoor Baker 8 Multi Fuel kit Assembled To fit: Place the MF grate (A) on the supports which are either side of the inside of the fire box with the wedge on the MF grate (A) facing up and forward.
-
Page 11: Ec Declaration Of Conformity
EC Declaration Of Conformity The Undersigned, representing the following: Manufacturer Dean Forge Ltd Dean Prior, Buckfastleigh, Devon, TQ11 0LS Herewith declare that the products: Description Product Code Dartmoor 5 STDFDA5, STDFFOH STDFFOL Dartmoor W5 STDFDAW5, STDFHU Dartmoor 6 STDFDA6 Dartmoor 8... - Page 12 Provisions to which the product conforms: Product: Roomheater fired by solid fuel as covered under the scope of the standards listed. Intended use: Space heating in residential building. Characteristic Performance Report Fire Safety Satisfies Dartmoor 5 Inset- STDFDA5I Co @ 13% 0² Wood 0.35% Ancit 0.40% 6700/1 5Kw @ 83.3% Wood –...
- Page 13 THE DEAN FORGE FABRICATION LTD STOVES GUARANTEE Dean Forge Fabrication Ltd offers a five year guarantee which covers the main body of the stove for manufacturing defects. In the event of any failure we will replace any defective part free of charge, labour cost excluded.
- Page 15 Dean Forge Fabrication Ltd Dean Prior Buckfastleigh Devon TQ11 0LS PRODUCT REGISTRATION Name ......................Address ...............................................................................Phone Number: ..........Suppliers Details: Name ......................Address ...............................................................................Phone Number: ..........Installers Details: Name ......................Address ......................................................................
