INSTALLATION MANUAL
EXTRA MOUNTING OPTIONS
NORDIC HVLS FAN SERIES
ENGLISH
T h e N o r d i c F a n C o m p a n y A p S
1
T h e N o r d i c F a n C o m p a n y A p S
Vers. 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the HVLS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nordic HVLS Series

Summary of Contents for Nordic HVLS Series

  • Page 1 INSTALLATION MANUAL EXTRA MOUNTING OPTIONS NORDIC HVLS FAN SERIES ENGLISH T h e N o r d i c F a n C o m p a n y A p S T h e N o r d i c F a n C o m p a n y A p S...
  • Page 2 HVLS fan to install on the market. INSTALLATION INFO: If you cannot install the NORDIC Fan using only the Standard Swivel mount, then you can utilize one of the additional mounting options, as described in this manual.

  • Page 3: General Safety Information

    WARNING To reduce the risk of fire, electric shock, or injury to persons, observe the following: Use this unit only in the manner intended by the manufacturer. If you have questions, contact the Nordic Fan Company or its representative. Before servicing or cleaning the unit, switch power off at service panel and lock the service disconnecting means to prevent power from being switched on accidentally.
  • Page 4 required Tools & accessories 10,13 & 17 MM 4 MM 10,13 & 17 MM SOCKET WRENCH ALLEN KEY WRENCH SOCKET WRENCH LIFT OR LEVEL DRILL SCAFFOLDING PREPARING UPPER MOUNT PLATE First, attach the swivel mount to the On the other side of the mount plate, Now you can install the upper mount upper mount plate using countersunk place the swivel mount, followed by...
  • Page 5 EXTRA MOunting options MOUNTING OPTION FOR WOOD & CONCRETE BEAMS Upper mount plate (1x) For concrete mounting: When L-shaped shim plates are instal- Using L-shaped shim plates as a tem- led, line up the upper mount plate and L-shaped shim plate (2x) plate, predrill 5mm holes in concrete bolt into L-shaped shim plates using beam.
  • Page 6 MOUNTING BRACKETS FOR STEEL-BEAM Placing the upper mount plate below Center the upper mount plate under Upper mount plate (1x) the I-beam. On each side of the the steel beam. Tighten using bolts as The Upper mount plate can I-beam, place 1 shim plate and hook specified until upper mount plate and accommodate I-beams with a 1 clamp plate above I-beam flange, as...
