Lexmark E230 How To Reset

How to Reset the Photoconductor Page Count Through the
Printer's Configuration Menu
German English Italian
Lexmark E230 Lexmark E232
Lexmark E238 Lexmark E240n Lexmark E330 Lexmark E332n
Solution
If using the Cancel (
via the printer's Configuration Menu. Do the following:
1. Enter the printer's Configuration Menu. To do this:
1. Turn off the printer.
2. Open the front cover, as shown below.
3. Press and hold the Continue ( ) button.
4. With the front cover open and the Continue button pressed down, power on the printer.
5. Hold the Continue button until all the lights cycle.
6. When just the Error light (!) is displayed, close the front cover. The top four lights of the operator panel
should come on, indicating that the printer is in configuration mode.
2. Print the Configuration Settings page. To do this:
Press and hold the Continue ( ) button until all of the lights flash. This page lists the functions within the
Configuration Menu. The functions are the non–indented items listed along the left edge of the page
(along the bottom as printed from printer). They are also unshaded.
Save this page for possible later use.
3. Reset the photoconductor page count as follows:
http://support.lexmark.com/index?pmv=print&page=content&locale=EN&userlocale=EN_US&id=HO2496
Lexmark E234
) button to reset the photoconductor page count does not work, you can also reset the page count
