TP active fun TP291 Instructions For Assembly, Maintenance And Safe Use page 11

8
M6 x25mm
Large washer
FA5095
2
TP291 Double Multiplay IN4040-J 05.04.18 A4.indd 11
M6 Lock
2
M6 x 35
nut
FA5164
FA5175
1
TP968 Slide
2
PM8387
M4 x 22mm
FA8444
2
7mm
The two pre-drilled holes in
the slide body will need to be
opened further with a 7mm
Forest Double Multiplay with Forest Green Wavy Slide
11
4
ASSEMBLY TIP
drill.
