TP821P Brecon
TP824P
(Frame supplied only - No Slide or Swing Seats)
Instructions for assembly, maintenance and safe use.
Please retain for future reference.
WARNING!
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN UNDER 36 MONTHS.
CONTAINS SMALL PARTS. CHOKING HAZARD.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE.
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
ADULT SUPERVISION IS REQUIRED
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 3 TO 12 YEARS.
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST BE FITTED BEFORE USE.
MAXIMUM COMBINED USER WEIGHT FOR THIS PRODUCT 200KGS
TP821P BRECON
TP821 Brecon 824P In0821-A 20.04.18.indd 1
(Slide and Swing Seats x 2 included)
TP821P
SINGLE SEAT USER WEIGHT - 60KGS
2.5 Hrs
Build Time
x2
Robovision Ltd t/a TP Toys
Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England
www.tptoys.com
TP824P
20/04/2018 11:09

Advertisement

loading
Need help?

Need help?

Do you have a question about the TP821P Brecon and is the answer not in the manual?

Questions and answers

Related Manuals for TP active fun TP821P Brecon

Summary of Contents for TP active fun TP821P Brecon

  • Page 1 TP821P Brecon (Slide and Swing Seats x 2 included) TP824P (Frame supplied only - No Slide or Swing Seats) Instructions for assembly, maintenance and safe use. Please retain for future reference. TP821P TP824P WARNING! THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN UNDER 36 MONTHS.
  • Page 2 200cm around the toys on all sides and 250cm above the toy. The safe play area must be free from all obstacles. Dimensions TP82P1 TP824P 240cm 179cm 119cm 276cm 124cm 340cm 340cm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 2 20/04/2018 11:09...
  • Page 3 Where cracks open up in excess of 5mm in width. • Where cracks of a significant width extend over half the total length of the timber. • Where cracks run through fixing points. TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 3 20/04/2018 11:09...
  • Page 4 MW0220 1015mm MW0228 795mm MW0221 825mm MW0226 1550mm MW0224 850mm 885-2 821-2 Brecon / 824P MW0222 2668mm 885-3 821-3 Brecon / 824P MW0200 2700mm MW0202 900mm MW0203 2250mm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 4 20/04/2018 11:09...
  • Page 5 FA8440 FA5174 70mm FA8439 40mm FA8380 PM1968 4 x 16mm FA4527 PM1007 PR5069 FB6039 FB6038 PR9598 TP928 824P PM1968 4 x 16mm FA4527 PM1007 PR5069 FB6052 FB6051 PR7757 TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 5 20/04/2018 11:09...
  • Page 6 TP821 & TP824P - Deck Assembly MW0228 795mm FB6039 70mm FA8439 15mm 120mm MW0222 2668mm 1300mm 1300mm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 6 20/04/2018 11:09...
  • Page 7 MW0222 2668mm 1300mm 1300mm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 7 20/04/2018 11:09...
  • Page 8 MW0225 612mm MW0226 1550mm 6 x 155mm FA9784 MW0225 3-5mm 3-5mm MW0225 60mm MW0225 3-5mm MW0225 MW0225 3-5mm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 8 20/04/2018 11:09...
  • Page 9 M8 x 120mm FA9771 M8 x25mm FA5174 FA8440 70mm FA8439 ASSEMBLY TIP Step ladders required. TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 9 20/04/2018 11:09...
  • Page 10 MW0223 700mm 4.5 x 40mm FA4517 13mm 13mm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 10 20/04/2018 11:09...
  • Page 11 MW0224 850mm 5 x 80mm FA4521 70mm 25mm 25mm 310mm 236mm 236mm 236mm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 11 20/04/2018 11:09...
  • Page 12 MW0218 1400mm MW0220 1015mm 4.5 x 40mm FA4517 MW0219 1210mm MW0221 825mm 600mm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 12 20/04/2018 11:09...
  • Page 13 4 x 16mm PM8387 FA4527 TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 13 20/04/2018 11:09...
  • Page 14 TP821 & TP824P - Swing Arm Assembly MW0203 2250mm FB6038 PR9598 TP821 TP824P M8 x25mm FA8440 70mm FA8439 15mm TP821 TP824P 750mm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 14 20/04/2018 11:09...
  • Page 15 With 1 nest swing (85cm dia) and 1 single roped accessory TP824P 100mm Single Roped Seat With 1 glide ride and 1 single roped accessory TP824P 100mm TP940 Glide Ride Position Single Roped Seat TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 15 20/04/2018 11:09...
  • Page 16 MW0200 2700mm M8 x25mm Washer FA8440 70mm FA8439 TP821 TP824P TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 16 20/04/2018 11:09...
  • Page 17 M8 x25mm FA8440 70mm FA8439 TP821 TP824P TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 17 20/04/2018 11:09...
  • Page 18 Generic view of Top Bar only. Actual Top Bar will vary depending on product purchased. ASSEMBLY TIP Make sure that the fixing points are centred on the legs. TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 18 20/04/2018 11:09...
  • Page 19 5 x 60mm FA9768 TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 19 20/04/2018 11:09...
  • Page 20 Attaching Swing Accessories TP928 Swing Accessories - Height adjustment 350mm PM1968 PM1007 4 x 16mm FA4527 Equal spacing TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 20 20/04/2018 11:09...
  • Page 21 M8 x25mm FA8440 70mm FA8439 PR5069 TP814 45° 45° 45° 45° 300mm 300mm 300mm 300mm 300mm 300mm TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 21 20/04/2018 11:09...
  • Page 22 TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 22 20/04/2018 11:09...
  • Page 23 TP821P Brecon & TP824P TP821 Brecon 824P In0821-A 20.04.18.indd 23 20/04/2018 11:09...
  • Page 24 Thank you Thank you for purchasing this product. Please register your new product on line at tptoys.com www.tptoys.com/customer/productregistration Find out about the guarantee for this product, visit www.tptoys.com/customer/pages/guaranteeinformation For customer services and help with your product, visit www.tptoys.com/customer/help Your TP Guarantee Number/Product Batch No is TP821 Brecon 824P In0821-A 20.04.18.indd 24 20/04/2018 11:09...
