TP368P
TP Forest Toddler Wooden Climbing Frame & Slide
TP369P
TP Forest Toddler Wooden Swing Set & Slide
Instructions for assembly, maintenance and safe use.
We constantly strive to improve our assembly instructions. To see the most current version of this
instruction for assembly, maintenance and safe use. Please visit the product page at tptoys.com
TP368P TP Forest Toddler Wooden
Climbing Frame & Slide
WARNINGS!
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT
SUITABLE FOR CHILDREN UNDER 36 MONTHS UNTIL
FULLY ASSEMBLED.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE.
ADULT SUPERVISION IS REQUIRED. TOY MUST BE ASSEMBLED
BY AN ADULT BEFORE USE.
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY
INSTALLED.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR
CHILDREN.
RETAIN PACKAGING FOR FUTURE REFERENCE.
TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 1
TP369P TP Forest Toddler Wooden Swing Set & Slide
x2
Build Time
Robovision Ltd t/a TP Toys
Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England
www.tptoys.com
WARNING: THIS PRODUCT IS INTENDED FOR USE BY
CHILDREN FROM AGES 18 MONTHS+.
WARNING: MAXIMUM COMBINED USER WEIGHT 100KGS
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST
BE FITTED BEFORE USE.
TP913X FoldAway Swing Seat
WARNING: THIS PRODUCT IS INTENDED FOR USE BY
CHILDREN FROM AGES 6 MONTHS TO 3 YEARS.
WARNING : MAXIMUM USER WEIGHT 45KGS
2 Hrs
Sand not included
07/02/2019 12:55

Advertisement

loading
Need help?

Need help?

Do you have a question about the TP368P and is the answer not in the manual?

Questions and answers

Related Manuals for TP active fun TP368P

Summary of Contents for TP active fun TP368P

  • Page 1 We constantly strive to improve our assembly instructions. To see the most current version of this instruction for assembly, maintenance and safe use. Please visit the product page at tptoys.com TP368P TP Forest Toddler Wooden Climbing Frame & Slide TP369P TP Forest Toddler Wooden Swing Set & Slide...
  • Page 2 Adult supervision is required at all times to ensure children play safely. When you dispose of this equipment please do so responsibly. TP368P Safe play free space area The safe play area refers to the zone extending 200cm around the toys on all sides and 250cm above the toy.
  • Page 3 Dimensions TP368P TP369P 915mm 750mm 915mm 915mm 750mm 750mm 1135mm 2527mm 2527mm 2527mm 1102mm 1102mm 2237mm Know About Wood Unlike steel, wood is a natural, organic material and each piece will be unique, bearing its own knots, cracks and variations in colour and, unlike steel, wood will react signifi cantly to changes in atmospheric conditions.

  • Page 4: Tools You Will Need

    Drill Bits Shovel Scissors Screwdriver Spanner Sockets Wrench Pozi #2 10 & 13mm 10 & 13mm Pozi #3 TP368P MW2200 802mm MW2212 310mm MW2201 455mm MW2213 310mm MW2202 820mm MW2214 310mm MW2215 378mm MW2203 780mm MW2216 255mm MW2204 570mm MW2217 560mm...
  • Page 5 Contents continued - Please check TP368P Continued MW2224 1230mm MW2226 970mm PM2001 TP368P Fixings SP3368 3.5 x 30mm 6 x 155mm FA4513 FA9784 M6 x 20mm M6 Nylon Insert FA5094 Dome Nut x103 4 x 40mm M8 x 75mm FA5192...
  • Page 6 TP368P TP Forest Toddler Wooden Climbing Frame & Slide M8 x 75mm TP369P TP Forest Toddler Wooden Swing Set & Slide FA6209 MW2224 1230mm M8 x 25mm MW2213 310mm MW2212 310mm FA7184 FA8163 IMPORTANT MW2213 Pre drilled holes are off centre.
  • Page 7 M8 x 25mm M8 x 75mm MW2212 310mm FA7184 FA8163 FA6209 MW2212 MW2212 MW2224 1230mm M8 x 75mm M8 x 25mm FA8163 FA6209 FA7184 IMPORTANT Pre drilled MW2224 holes are off centre. MW2224 TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set &...
  • Page 8 M8 x 100mm M8 x 75mm MW2212 310mm FA8163 FA9701 FA6209 M8 x 25mm FA7184 M8 x 75mm MW2212 M8 x 75mm MW2212 M8 x 100mm MW2212 M8 x 100mm MW2212 M8 x 25mm MW2223 1130mm M8 x 75mm FA7184 FA6209 MW2201 455mm M8 x 100mm...
  • Page 9 M8 x 25mm MW2223 1130mm M8 x 75mm FA7184 FA6209 MW2201 455mm M8 x 100mm FA9701 FA8163 IMPORTANT Pre drilled holes are off centre. M8 x 75mm M8 x 75mm MW2201 M8 x 100mm M8 x 100mm MW2223 MW2200 802mm 6 x 155mm FA9784 MW2222 1000mm...
  • Page 10 6 x 155mm FA9784 IMPORTANT ASSEMBLY TIP Deck Support must be LEVEL. 90˚ 531mm 531mm 531mm 531mm 531mm MW2200 802mm 6 x 155mm FA9784 IMPORTANT ASSEMBLY TIP Deck Support must be LEVEL. Level TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set &...
  • Page 11 MW2208 662mm 6 x 155mm FA9784 MW2208 IMPORTANT ASSEMBLY TIP Use Deck Board for correct fixing height position of MW2208 Deck Board must be level Level MW2208 Deck Board MW2208 Deck Board MW2208 TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set &...
  • Page 12 MW2210 415mm MW2209 250mm 5 x 60mm FA9768 MW2210 Deck Board must be level Baton IMPORTANT Deck Board ASSEMBLY TIP MW2210 Use Deck Board for correct fixing Baton height position of Battons Deck Board Baton MW2209 MW2209 TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set &...
  • Page 13 MW2202 820mm MW2203 780mm MW2204 570mm 4 x 40mm FA4511 TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set & Slide TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 13 07/02/2019 12:55...
  • Page 14 MW2205 455mm 4 x 40mm FA4511 Space boards equally MW2218 1180mm 4 x 40mm FA4511 Space boards equally TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set & Slide TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 14 07/02/2019 12:55...
  • Page 15 MW2217 560mm 4 x 40mm FA4511 MW2219 940mm 4 x 40mm FA4511 MW2207 500mm TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set & Slide TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 15 07/02/2019 12:55...
  • Page 16 MW2215 378mm MW2221 258mm 4 x 40mm FA4511 Equal spacing Equal spacing 4 x 40mm FA4511 TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set & Slide TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 16 07/02/2019 12:55...
  • Page 17 MW2220 970mm MW2221 258mm 4 x 40mm FA4511 TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set & Slide TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 17 07/02/2019 12:55...
  • Page 18 4 x 40mm FA4511 MW2219 940mm 404mm 404mm No Gap TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set & Slide TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 18 07/02/2019 12:55...
  • Page 19 4 x 40mm FA4511 MW2216 255mm 3.5 x 30mm FA4513 MW2226 970mm 75mm 75mm TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set & Slide TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 19 07/02/2019 12:55...
  • Page 20 MW2206 667mm MW2214 310mm 4.5 x 40mm FA4517 210mm 210mm 120mm 120mm 4.5 x 50mm FA9705 TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set & Slide TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 20 07/02/2019 12:55...
  • Page 21 5 x 60mm FA9768 IMPORTANT ASSEMBLY TIP ENSURE FIXINGS SCREW INTO DECK SUPPORT TP368P - Now go to Stage 33 - Staking to complete build MW2225 1000mm 4.5 x 50mm FA9705 PR7691 TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set &...
  • Page 22 MW1233 1400mm 30mm FA5124 M8 x 25mm FA5174 FA7184 M8 x140mm FA9975 M6 x 70mm MW1226 835mm FA5170 FA5192 FA9764 TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set & Slide TP368 369 Forest Toddler Wooden Swing Set & Slide In3689-C 07.02.2019.indd 22 07/02/2019 12:55...
  • Page 23 M8 x 25mm FA8163 FA7184 M8 x 140mm FA9775 FA9791 M8 x 25mm FA8163 FA7184 PM1007 ASSEMBLY TIP Remove Karabiners from Seat ASSEMBLY TIP Use Mallet to firmly locate hook bolt in pilot hole TP Forest Toddler Wooden Climbing Frame & Slide TP Forest Toddler Wooden Swing Set &...
  • Page 24 M6 x 70mm Not Supplied FA5094 FA5094 FA5170 FA5170 Shovel PM2001 PM2001 FA5192 FA5192 TP368P TP368P & TP369P TP814 300mm 300mm Dig holes: 300mm x 300mm 300mm x Mark leg/hole position. 300mm deep. Ensure the stakes are positioned into the setting Post-Mix concrete.
  • Page 25 All about your New TP913X FoldAway Swing Seat Important Before you use your TP FoldAway Swing Seat please read the safety information carefully and follow its advice at all times. FC9908 x2 Karabiner with Nylon Bush. The karabiners should always be used to attach the seat to the frame.
  • Page 26 Attaching your swing seat to the frame Unfolding the Important! Folding away the Swing Seat (after use) Swing Seat Check frame attachment To fold away - simply reverse the below steps. Before use, please ensure that the sides of the seat are fully inserted to the frame.
  • Page 27 Care and Maintenace of your swing seat The TP FoldAway Swing Seat is designed with maximum comfort for your child. Due to the soft materials, we do not recommend leaving it outside for long periods. Please look after if by taking it inside when not in use. To remove light stains, we recommend using a damp cloth.
  • Page 28 Thank you Thank you for purchasing this product. Please register your new product on line at tptoys.com www.tptoys.com/customer/productregistration Find out about the guarantee for this product, visit www.tptoys.com/customer/pages/guaranteeinformation For customer services and help with your product, visit www.tptoys.com/customer/help Your TP Guarantee Number/Product Batch No is TP368 369 Forest Toddler Wooden Swing Set &...
