KMC Controls HPO-9001 Installation Manual

CONTENTS
Introduction .............................................. 1
Mount in Snap Track ................................... 1
Connect Controller ..................................... 2
Connect Sensors ........................................ 2
Connect Power .......................................... 2
Configuration and Programming ................... 3
Sample Applications ................................... 4
Active NetSensor Determination ................... 4
Troubleshooting ........................................ 4
Accessories and Replacement Parts ............. 5
Important Notices ...................................... 5

INTRODUCTION

The HPO-9001 Distribution Module allows up to
eight STE-9000 series NetSensors (with firmware
version R5.1.0.10 or later installed) to be linked to
one BAC-5900/9000/9300 series controller (with
firmware version R1.2.0.9 or later installed). The
module provides power (from a connected 24 VAC
transformer) and addressing (according to the
connected port) for each NetSensor.
Alternately, it allows one STE-6010/6014/6017
analog temperature sensor to be connected to a
controller along with up to seven NetSensors.
NOTE: Applications require custom
configuration and programming. See
Configuration and Programming on
page 3.
The module may be connected to a controller with
a standard (Category 5 or better) Ethernet patch
cable up to 150 feet (45 meters) long. Cables from
the module to any NetSensors may also be up to
150 feet (45 meters) long. See
Replacement Parts on page
NOTE: For module specifications, see that
section in the
NetSensor
kmccontrols.com.
KMC Controls, 19476 Industrial Drive, New Paris, IN 46553
HPO-9001 Distribution Module
Accessories and
5.
Conquest STE-9000
data sheet on the web at
For physical and ESD (ElectroStatic Discharge)
protection, the module board should be mounted
inside a suitable enclosure using the supplied Snap
Track (or track that is integrated into the enclosure).
Complete the steps in the following sections to
install the module.

MOUNT IN SNAP TRACK

1. Install the (included) Snap Track
enclosure using the provided screws.
NOTE: When mounting in an enclosure, provide
clearance for cables plugged into ports.
2. Snap the HPO-9001 board into the Snap Track
slots .
1
NOTE: If mounting in an
which has Snap Track integrated into its
lower section, the Snap Track included
with the HPO-9001 does not need to be
installed. The HCO-1101 enclosure can
mount on a flat surface (via screw holes)
or on a DIN rail (via an integrated DIN rail
channel).
NOTE: If protection from dust is also a
factor, mount in a NEMA 1 (IP10)
rated enclosure such as an
1034/1035/1036.
/ 877-444-5622 / Fax: 574-831-5252
Installation Guide
NOTICE
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE DEVICES
in an
1
1
HCO-1101 enclosure,
HCO-
/ www.kmccontrols.com
