Mounting

The VEP–3419 is designed for full flow/fail-safe to the system
return. The VEP–3719 is designed for systems requiring full flow/
fail-safe to the coil.
1. Clean the lines upstream from the valve. Remove
debris >0.06" (.015 mm).
2. Install as close as possible to the coil in a vertical position
(actuator over the valve).
CAUTION: Mount valve with the actuator in the upright position,or at
most a 45° angle, to prevent condensation collecting in the actuator
housing.
3. Allow a minimum clearance of 1-1/2 " (38mm) between the top
of the actuator and the nearest obstruction. This permits
removal of the actuator yoke and replacement of the bonnet
assembly.
4. Align system flow with arrow on valve body.
5. Pipe the VEP–34/37 so the side outlet feeds the return of the
systems. This outlet uses a metal to metal seat and may not be
leak tight. Align system flow with arrow on valve.
6. Seal valves with approved valve sealant.
7. Connections:
3-15/32" (88)
1/2" 3-Way Diverting Electronic Control Valves
Installation Guide
Inlet 1/2" FPT
Outlets 1/2" MPT
VEP-3419
any
Piping VEP–3419/3719 SERIES
VEP-3419 or VEP-3719 with Fail-safe
VEP–3419, VEP–3719 Series
Top of Actuator
