Chapter 7 - Specifications - I-Motioncaddys IM4 Owner's Manual

CHAPTER 7 - SPECIFICATIONS

Item
Motor
Battery
Controller
Accelerate
Charger
Dimension
Weight (without batteries)
Carrying capacity
Maximum speed
Low speed
Slope climbing capacity
Brake range
Turning radius
Brake method
Wheel base
Minimal ground clearance
Tyre
Tyre pressure
Parameter
36V 1300 Watt permanent magnetism
12V 48AH x 3 / 12V 45AH x 3 / 12V 75AH x 3
Curtis controller 1227-3402 dc36v / 160A
Hall accelerator continuous variable speed system
Full automatic efficiency pulse charger 5 Amp or
8 Amp
1.27 x 0.82 x 1.05m
105kg
200kg
13-15km/h
4-6km/h
17 degrees
< 4m 3 secs
< 3m
Electromagnetic & mechanical brake
90cm
11cm
32.5cm x 15cm 4 Wheels
Front 18 psi and Rear 20 psi
