1. CONDITIONS FOR USE
This micro abrasive blaster may only be operated:
• Indoors;
• Below 6500 ft above sea level altitude;
• Ambient air temperature between 40°-105°F (5-40°C);
• Maximum relative humidity of 80% at 88°F;
• Power supply current fluctuations does not exceed 10% of nominal value;
• Under level 2 contamination conditions;
• Supply cool, dry air only, at a maximum pressure of 150 PSI.
2. SAFETY
• Always disconnect the unit from the compressed air and power sources before beginning any
maintenance.
• When working with the tank wear protective glasses to protect your eyes.
• Any abrasive material on the o-ring may lead to leakage and early wear of the o-ring. After filling, clean the
thread and o-ring before applying the lid.
• Solvents will create cracks in the jar and weaken the jar (danger of explosion!). Clean the lid and tank only
with a dry cloth. Do not write or adhere anything to the jar or lid.
• Check for damages on the lids and tanks regularly and replace them if there is any doubt of the structural
integrity.
• Before operation, check to make certain the lid is secured properly. Using the product without the lid secured
will create a serious explosive hazard.
• Never operate the blasting units without suitable dust extraction and appropriate protective gear. The type
of dust extraction should be based on the type dust generated. Ask the proper authorities.
• Never direct the blasting material towards eyes or unprotected areas of skin. Improper use can result in risk
of eye or skin injuries.
• Never work with the glass door open.
• Caution: Failure to wear eye protection can result in eye injury. Wear proper eye protection to protect your
vision.
• Do not depress the foot switch when only the compressed air supply hose is connected. The loose hose could
wrap around itself and cause serious injury.
• Unplug the unit from the wall before changing out the LED light. Do not squeeze or bend the light tube. Always
wear gloves or use a towel to protect your hands from glass splinters.
• Inspect power cords before beginning operation. The unit may not be used if the power cord is damaged.
2.1 Liability Exclusion - Vaniman Manufacturing shall be absolved from all claims for damages and warranty if:
• The product is used for any purpose other than it was designed for.
• The product is altered in any way other than those described in the operating instructions.
• The product is repaired by any body other than an authorized facility or if any parts other than Vaniman OEM
parts are used.
• The product continues to be employed, despite obvious safety faults.
140 N. Brandon
P.O. Box 74, Fallbrook, CA, USA 92088
1-800-VANIMAN (826-4626) USA
www.vaniman.com
SANDBLASTER SAFETY 7/15Page 1

Advertisement

loading

Summary of Contents for Vaniman SANDSTORM PRESTIGE I/O

  • Page 1 • The product is altered in any way other than those described in the operating instructions. • The product is repaired by any body other than an authorized facility or if any parts other than Vaniman OEM parts are used.
  • Page 2: Packing List

    SANDSTORM PRESTIGE I/O PACKING LIST 1 - SandStorm Prestige I/O 1 - Instructions 1 - DC Power Supply INSTALLATION & OPERATION 1. Remove all packing material. 2. Plug DC Power Supply into electrical outlet and into the right side of the light assembly.
  • Page 3: Maintenance

    11. Securely attach the optional dust collection system to the hole in the back of the cabinet. A dust collector is strongly recommended to contain the dust inside the cabinet. Vaniman recommends the SandVac for single blaster use or the StoneVac II for high volume or multiple blasting systems.
  • Page 4 Replace when necessary. Moisture Vaniman blasters include a Filter for small amounts of oil and moisture. If moisture causes the media to clump or cake in the tanks, improper media flow will result. Be sure the air supply is relatively oil and moisture free.
  • Page 5: Replacement Parts

    97951 Cuff Holder 2260 Not Shown Cuff (Black Cloth) 2033XL Window Gasket Kit 2030B Not Shown Blow Off Gun 2285 140 N. Brandon P.O. Box 74, Fallbrook, CA 92088 1-800-VANIMAN (826-4626) www.vaniman.com    SANDSTORM PRESTIGE I/O-I-03/14 Page 4...
  • Page 6 SANDSTORM PRESTIGE I/O PLUMBING Air Supply In Foot Pedal 140 N. Brandon P.O. Box 74, Fallbrook, CA 92088 1-800-VANIMAN (826-4626) www.vaniman.com    SANDSTORM PRESTIGE I/O-I-03/14 Page 5...
