This dust collector is designed to run on 115 volt alternating current, 60 Hz
supply voltage in temperatures ranging from -10 to +40 degrees celcius. With
a maximum current usage of 15 amps. The plug on the unit labeled "Power"
is for the supply line cord provided. The supply plug in the wall must have a
wired ground and if the back cover is removed for any reason, do not bypass the
protective earthing.
This dust collector is to be used for capturing fine aerosols. Not suitable for
direct liquid suction.
When placing the unit in a location be sure that the power connector is
accessible at all times. Any side of the dust collector that has a vent on it must
be a minimum of 2 inches from any obstruction, and have a vent area of 20
square inches to allow ventilation to ambient room air. This will keep the unit cool
and ensure a longer motor life.
Failure to comply with the precautions listed here or any others for this
equipment may cause electrical shock or equipment failure.
- Alternating Current
- Caution, risk of electrical shock
25799 Jefferson Ave. Murrieta, CA 92562 ● 1-800-VANIMAN (826-4626) ● www.vaniman.com ● sales@vaniman.com
Warnings and Precautions
VANGUARD GOLD MOBILE
EXTRAORAL SUCTION
VANGUARD GOLD MOBILE REV1 06/20
Page 1
Advertisement
Related Manuals for Vaniman VANGUARD GOLD MOBILE
Summary of Contents for Vaniman VANGUARD GOLD MOBILE
- Page 1 Failure to comply with the precautions listed here or any others for this equipment may cause electrical shock or equipment failure. - Alternating Current - Caution, risk of electrical shock 25799 Jefferson Ave. Murrieta, CA 92562 ● 1-800-VANIMAN (826-4626) ● www.vaniman.com ● sales@vaniman.com VANGUARD GOLD MOBILE REV1 06/20...
-
Page 2: Packing List
The unit can be turned on and off by depressing the foot remote. DISINFECTION INSTRUCTIONS 1. Using disinfectant, spray outside and inside of Flex Hose between sessions. Unit may remain on during this step. 25799 Jefferson Ave. Murrieta, CA 92562 ● 1-800-VANIMAN (826-4626) ● www.vaniman.com ● sales@vaniman.com VANGUARD GOLD MOBILE REV1 06/20... -
Page 3: Filter Replacement Instructions
3. Motor Brushes - This long life motor does not have replaceable brushes. Replacement motors can be ordered as P/N 97041. 25799 Jefferson Ave. Murrieta, CA 92562 ● 1-800-VANIMAN (826-4626) ● www.vaniman.com ● sales@vaniman.com VANGUARD GOLD MOBILE REV1 06/20... -
Page 4: Replacement Parts
EXTRAORAL SUCTION REPLACEMENT PARTS The following items are offered to enhance the usage of your quality Vaniman unit. These items can be order through your supplier using the following part numbers. Please feel free to contact Vaniman Mfg. Co. with questions regarding our products. -
Page 5: Hepa Filter
The filter is designed to be added to Vaniman Vanguard 1X and 2X, Van-I-Vac, and Voyager dust collectors internally. It is a HEPA grade filter to insure effective filtration.
