TECHNICAL SPECIFICATIONS

DIMENSIONS
Height
Height with container
Width
Depth
Overall dimension
with door open
Height of cabinet
Weight
C l o b i ì r
K . g
Power supply voltage
Frequency
Installed power
© by NECTA VENDING SOLUTIONS SpA
= 650 mm
= 750 mm
= 410 mm
= 490 mm
= 830 mm
= mm. 820
E s p e r s s o n I s a t
3 8 3 3
230 V~
50 Hz
1300 W
CUP DISPENSER
Suitable for cups with a rim diameter of 73-74 mm. with a
capacity of approximately 170 cups.
PAYMENT SYSTEM
The machine is supplied with all prearrangement for a front
validator. Specific kits are provided for the installation of
payment systems with Executive, MDB or BDV protocol.
The machine can accommodate the "cashless" payment
system, while the "change giver" payment system must be
installed in the special support cabinet (optional).
SALES PRICES
A different programmable price can be set for each selec-
tion;
the standard setting has the same sales price for all
selections.
COIN BOX
Made of plastic with lock as optional accessory.
WATER SUPPLY
From the mains, with a water pressure of 5 to 85 N/cm
A water supply tank can be installed in the support cabinet
(optional).
AVAILABLE ADJUSTMENTS
Grade of grinding for espresso coffee;
coffee and water doses by volume;
time adjustment for instant products.
Temperature control
Factory set on the correct operating temperature. A trim-
mer located on the control board allows small adjustments
(as necessary).
CONTROLS
- Presence of cups
- Presence of water
- Presence of coffee
- Operating temperature reached
- Cup release microswitch
SAFETY DEVICES
- Door switch
t n
- Presence of coffee waste container (Espresso models
only)
- Manual-reset boiler safety thermostat
- Air-break float jamming (only with water supply from
the mains)
- Overflow solenoid valve (only with water supply from
the mains)
- Time protection for:
Pump
Coffee unit ratiomotor
Coffee grinder
4
