LG MODBUS-RTU User Manual page 14

Paramet
er Parameter Name
Address
0x000A Output Frequency
0x000B Output Voltage
0x000C DC Link Voltage
0x000D Output Power
0x000E Sequence Monitor
0x000F Trip information
modbus-rtu iS5 manual.doc 10
Unit Read/Write
0.01 Hz R
0.1 V R
0.1 V R
0.1 kW R
- R
- R
Data Value (Hex)
BIT 0 : Stop
BIT 1 : Forward Run
BIT 2 : Reverse Run
BIT 3 : Fault (Trip)
BIT 4 : Accelerating
BIT 5 : Decelerating
BIT 6 : Output Frequency
Arrival
BIT 7 : DC Braking
BIT 8 : Stopping
BIT 9 :Not Available
BIT 10 : BrakeOpen
BIT11: Forward Run
Command
BIT 12 : Reverse Run
Command
Bit 0:OCT1, Bit 1: OV, Bit 2:
EXT-A Bit 3: BX,
4:OCT2, Bit 5: GF, Bit 6:
OH, Bit 7: ETH, Bit 8: OLT,
Bit 9: HW-diag, Bit10:EXT-
B, Bit11:FO Bit12:OPT,
Bit13:PO Bit,14:IOLT,
Bit15:LV
Bit
