This manual covers units shipped April 2017 to date.
(Hazards: English, French)
Language: English
Dok-Guardian™ HD
(Heavy Duty) Safety Barrier
Installation/Service/Owner's Manual
SAFETY 2
Wardens 7
Curtain 10
Electrical 11
Exterior Use 17
PARTS 20
Actuator 25
Interlock 26
WARRANTY 28
Model #: DGHD, DGHDCM
Publication: AMEN00033 2019-03-29
9
Manual Part #: 54450037
Advertisement
Table of Contents
Related Manuals for RITE-HITE Dok-Guardian HD
Summary of Contents for RITE-HITE Dok-Guardian HD
-
Page 1: Table Of Contents
Dok-Guardian™ HD (Heavy Duty) Safety Barrier Installation/Service/Owner's Manual This manual covers units shipped April 2017 to date. NOTICE TO USER 2 SAFETY 2 INSTALLATION Preparation 3... -
Page 2: Notice To User
Rite-Hite technical support at (US) 888-456-3625, blessures graves. (SA) +55 21 99616 4421, (EU) +49-5693 98700 The Rite-Hite® products in this manual are covered by one or more CAUTION / ATTENTION of the following US patents: 7207370, 7832451, 7775252, 6279276,... -
Page 3: Installation
Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual SAFETY INSTALLATION General Preparation The Dok-Guardian is shipped to order CAUTION / ATTENTION If ordered/shipped correctly, go to "Wardens" (page 7). Barricade the work area until the unit(s) have been If you need to alter the orientation from what was ordered/ completely installed. -
Page 4: Change Orientation
Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual INSTALLATION Change Orientation To modify the Dok-Guardian wardens to pull in the opposite direction: Storage Warden 1 Separate the roller support (A) from the storage warden (B) by removing the 7 bolts, washers, and nuts (C) 2 Turn the roller support completely upside down and refasten (according to Right or Left mount)... - Page 5 Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual INSTALLATION Change Orientation Continued Curtain Lead Bar Left to Right Pull Right to Left Pull Pin orientation does not NOTE: change for either pull direction Legs of handle and legs of pin must always point to one another NOTE: Interdeterrent...
- Page 6 Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual INSTALLATION Change Orientation Continued Interlock Assembly (if equipped) 10 11 Warden STORAGE SIDE WARDEN. AS LEFT TO RIGHT PULL Latch Bracket Interlock Assembly RECEIVER SIDE WARDEN. Left to Right pull Right to Left pull AS LEFT TO RIGHT PULL Shown: Back side (Left to Right pull) Flush...
-
Page 7: Wardens
Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual INSTALLATION Wardens Footprint: Standard 16.00in [406.40mm] 15.50 13.50in [393.70mm] [342.90mm] Footprint: Common Storage Wardens Receiver Warden First Unit "A" Middle Unit(s) "B" End Unit "C" Multiple units may be labeled "B" Figure 5 2 Unit "A": Position to begin the chain The COW Reference the survey drawing completed by the salesperson if it is available... - Page 8 Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual Titan HD Concrete Anchor Installation Ins INSTALLATION Tools Required: Wardens Hammer Drill with ¾” x 8” Concrete Drill Bit Continued Impact Wrench with 1-1/8” Impact Socket Anchoring to Concrete* 1 Tighten all rails and brackets securely before anchoring the system to concrete Installation: The Dok-Guardian Heavy Duty Safety Barrier requires a...
-
Page 9: Interlock/Interdeterrent (Optional)
Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual INSTALLATION Interlock/Interdeterrent Interlock / Interdeterrent Switch (OPTIONAL) 1 Determine the correct location of latch bracket (D) WARNING / AVERTISSEMENT on warden to have the curtain provide the proper stopping distance from impact Interlock assembly is not intended for exterior use 2 Ensure concentricity of magnet, large circular hole in or environments where it may get wet. -
Page 10: Curtain
Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual INSTALLATION Curtain Tensioning WARNING / AVERTISSEMENT Spring under tension. DO NOT unwind the roller spring! Ressort sous tension. NE PAS dérouler le rouleaux à ressort! Adjustment 1 Adjust curtains, after wardens are secured in place Figure 7 2 Pull the curtain across the door opening and secure If the top of the curtain “sags”... -
Page 11: Electrical
Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual INSTALLATION Electrical Publication: AMEN00033 2019-03-29... - Page 12 Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual INSTALLATION Electrical Publication: AMEN00033 2019-03-29...
- Page 13 Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual INSTALLATION Electrical Publication: AMEN00033 2019-03-29...
- Page 14 Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual INSTALLATION Electrical Publication: AMEN00033 2019-03-29...
- Page 15 Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual INSTALLATION Electrical Publication: AMEN00033 2019-03-29...
-
Page 16: Operation
Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual OPERATION Storage Warden Receiver Warden STORAGE SIDE WARDEN. AS LEFT TO RIGHT PULL STORAGE SIDE WARDEN. AS LEFT TO RIGHT PULL Left mount unit with Left to Right pull shown RECEIVER SIDE WARDEN. AS LEFT TO RIGHT PULL Figure 8 Extend Barrier... -
Page 17: Maintenance
Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual MAINTENANCE Planned Maintenance CUSTOMER SALES ORDER #: SERIAL #: DATE: DAILY MONTHLY INSPECT AND PERFORM THE FOLLOWING: Cycle the unit Inspect unit for damage from impact Look for tears in the curtain or steel that is bent or damaged ... -
Page 18: Re-Tensioning Roller Assembly
Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual MAINTENANCE Re-Tensioning Roller Assembly WARNING / AVERTISSEMENT Spring under tension. DO NOT unwind the roller spring! Ressort sous tension. NE PAS dérouler le rouleaux à ressort! The spring roller assembly comes from the factory pretensioned In normal use, the roller assembly will not need adjusting or re-tensioning Use the following procedure only if the roller assembly is allowed to unwind... - Page 19 Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual Publication: AMEN00033 2019-03-29...
-
Page 20: Parts
SPRT,RLR STORAGE,DOK-GRDN HD 65650012 POST,RECEIVER,DOK-GRDN HD 12420026 BAR,RETAIN,STORAGE,DOK-GRDN 67900005 SCR,HHMS,1/2-13X1-1/2,GR5,ZNC 74150001 WSHR,FLAT,1/2X1-3/8X7/64,ZNC 55650004 NUT,HEX,NYL LOCK,1/2-13,ZNC 67900048 BLT,CARG,1/2-13X1-1/2,GR5,ZNC 65300028 PLUG,PLSTC,YLW,9/16 67860001 SCR,HWH,DR/TP,1/4-14X1-1/4 67860101 SCR,HWH,DR/TP,1/4-14X1 1041.XXX ASSY,BAR,CURT,RECEIVER 53850621 LABEL,BARRIER,DOK-GUARDIAN HD 17250203 CBOX,DOK-GUARDIAN,LIGHT COMM 54270036 LIGHT,DOK LOK,ASSY,12/24V LED 11230005 ANCHOR,CONCRETE,HH,3/4X7,ZINC <1203A002_08072018pdf:7> Publication: AMEN00033 2019-03-29... - Page 21 SPRT,RLR STORAGE,DOK-GRDN HD 72600074 POST,RECEIVER,DOK-GRDN HD 65650012 BAR,RETAIN,STORAGE,DOK-GRDN 12420026 SCR,HHMS,1/2-13X1-1/2,GR5,ZNC 67900005 WSHR,FLAT,1/2X1-3/8X7/64,ZNC 74150001 NUT,HEX,NYL LOCK,1/2-13,ZNC 55650004 BLT,CARG,1/2-13X1-1/2,GR5,ZNC 67900048 PLUG,PLSTC,YLW,9/16 65300028 SCR,HWH,DR/TP,1/4-14X1-1/4 67860001 SCR,HWH,DR/TP,1/4-14X1 67860101 ASSY,BAR,CURT,RECEIVER 1041xxx LABEL,BARRIER,DOK-GUARDIAN HD 53850621 CBOX,DOK-GUARDIAN,LIGHT COMM 17250203 LIGHT,DOK LOK,ASSY,12/24V LED 54270036 ANCHOR,CONCRETE,HH,3/4X7,ZINC 11230005 Publication: AMEN00033 2019-03-29...
- Page 22 Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual PARTS DGHDCM.XXX DGHDCM.XXX DGHDCM.XXX DGHDCM.XXX First Unit No Latch Bracket 1 Storage Warden No Receiving Warden FIRST UNIT Note absence of receiving latch FIRST UNIT FIRST UNIT & receiving post. Note absence of receiving latch Note absence of receiving la &...
-
Page 23: Interdeterrent, Interlock And Latch
1041.XXX 1041.XXX 1041.XXX Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual PARTS 1041.XXX 1041.XXX 1041.XXX Interdeterrent, Interlock and Latch 1041.XXX None, No Latch Interdeterrent, No Latch Interlock, No Latch NONE, NO LATCH INTERDETERRENT, NO LATCH INTERLOCK, NO LATCH NONE, NO LATCH INTERDETERRENT, NO LATCH NONE, NO LATCH INTERDETERRENT, NO LATCH... -
Page 24: Curtain Lead Bar
Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual PARTS Curtain Lead Bar No Interdeterrent, No Interlock Interdeterrent Interlock NONE (USE 1041XXX) 12420029 12420030 BAR, ASSY, CRTN, DKGRDN, [LEVEL] BAR, ASSY, CRTN, INTERDETERRENT BAR, ASSY, CRTN, INTERLOCK DESCRIPTION NO INTERDETERRENT, INTERDETERRENT INTERLOCK PART # NO INTERLOCK... -
Page 25: Interdeterrent Switch
Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual PARTS Interdeterrent Switch 76210073 SWITCH, ASSY, INTERDETERRENT 53760029 KIT, MAG, INTERD, DOK-GUARDIAN DESCRIPTION SW, MAG REED, NO, 05A, 8ft CORD SCR, RHMS, PHLP, #10-24 X2, SS NUT, HEX, NYL LOCK,#10-24, ZNC MAG,13LB,1OD,3/16HOLE, ZNC Actuator Lever not included DESCRIPTION... -
Page 26: Interlock
Dok‑Guardian™ HD Safety Barrier Rite‑Hite ® Installation/Service/Owner's Manual PARTS Interlock 11600018 ASSY, INTRLK, SHRD, DG, 10MM, L2R 11600022 ASSY, INTRLK, SHRD, DG, 10MM, R2L DESCRIPTION STANDOFF, NYLON, PCB, ADHSV, 1/4in PCB, ACTUATOR, DOK-GUARDIAN SHRD, SW, INTERLOCK, 10MM, DKGRDN SCR, RHMS, PHLP, #8-32X1, ZNC NUT, HEX, SERRATED, #8-32x1in, Z LVR, LINKAGE, INTRLCK, DKGRDN SCR, RHMS, PHLP, #8-32X3/4, ZNC... - Page 27 Rite‑Hite Dok‑Guardian™ HD Safety Barrier ® Installation/Service/Owner's Manual Publication: AMEN00033 2019-03-29...
- Page 28 Product claimed to be defective and shall, at Rite-Hite's option, either (x) grant Rite-Hite or its agent access to Owner's premises for the purpose of repairing or replacing the Product or (y)
