Tycon Power Systems Wireless EZ-Bridge AC Manual page 3

High performance point to point wireless bridge system
Hide thumbs
Table of Contents

Advertisement

Simplified Hook-Up Diagram
Antenna "B"
POE Port
LAN Port
All connections beyond this point
must happen after EZ-Bridge Set-Up
and Verification Tests.
LAN Port
LAN Port
Router or Switch
Typical IP Device(s)
Cameras, Access Points,
PC
Radios, Other.
3
