11ac Tri-Band 2200Mbps High Power Outdoor Access Point

Description:

AP11-Dual-IP67 is an Qualcomm Solution 11ac high power industrial use Outdoor access point with tri-

band, 2200Mbps Wi-Fi speed (2.4GHz 300Mbps, 5.8GHz 900Mbps, 5.8G 900Mbps), equipped with

Gigabit WAN port, fast Ethernet data rate make 200 end users access into it, to enjoy the seamless HD

movies, streaming, online gaming, wireless security and other bandwidth-intensive tasks, useful in high

density user access environment.

Outdoor shell with Lightning Protection, Temperature Adaptive

AP11-Dual-IP67 with metal IP67 level waterproof, dust proof and sunscreen shell, PCB board support

Common mode ±6KV Different mode ±2KV lightning protection, which avoid the damage from dust,

thunderstorm weather. Meantime, it adaptive to various environment, the working temperature can be

normal at -30℃ to 70℃, Suit for any country and any environment.

High Power design, N connector for external antenna, more range and

stable signal

Designed in Power Amplifier on PCB board, the power can be 300mW high power, N type water proof

connector,can connect with panel/omni outdoor antenna based on request, greatly increase the Wi-Fi

range and supply the stable Wi-Fi signal for users.

Power over Ethernet

AP11-Dual-IP67 has integrated IEEE802.3at Power over Ethernet (PoE), for easy installation and

lower cost. So it can be installed in areas where power outlets are not readily available,

eliminating the mess of altering existing network infrastructure.

MU-MIMO, Wave2.0 Technology

Comply with Wave2.0 Technology, it adopt 256QAM modulation, support MU-MIMO (Multi-User

Multiple-Input Multiple-Output), 8 Spatial Steams, greatly to improved the communication

efficiency

Technical specifications are subject to change without prior notice. Please check www.tyconusa.com for the latest information.

www.tyconusa.com

Model: AP11-Dual-IP67

Need help?

Do you have a question about the AP11-Dual-IP67 and is the answer not in the manual?

Page 1 Model: AP11-Dual-IP67 Description: AP11-Dual-IP67 is an Qualcomm Solution 11ac high power industrial use Outdoor access point with tri- band, 2200Mbps Wi-Fi speed (2.4GHz 300Mbps, 5.8GHz 900Mbps, 5.8G 900Mbps), equipped with Gigabit WAN port, fast Ethernet data rate make 200 end users access into it, to enjoy the seamless HD movies, streaming, online gaming, wireless security and other bandwidth-intensive tasks, useful in high density user access environment.
Page 2 11ac Tri-Band 2200Mbps High Power Outdoor Access Point Model: AP11-Dual-IP67 Beamfrorming, DFS, Airtime Fairness, Band Steering, OFDM support AP11-Dual-IP67 support many functions like Beamfrorming, DFS(Dynamic Frequency Selection), Airtime Fairness, Band Steering ( 5G Prior), OFDM( Orthogonal Frequency Division Multiplexing) , RF Power adjustable to improve the performance and Wi-Fi stability.
Page 3 11ac Tri-Band 2200Mbps High Power Outdoor Access Point Model: AP11-Dual-IP67 Product Spec.: Hardware: Chipset Qualcomm IPQ4019+QCA9886+QCA8075 Standard 802.11ac/b/g/n, MU-MIMO technology Memory 512MB DDR3 RAM Flash 32MB Interface 1 * 10/100 /1000Mbps RJ45 WAN Port 1 * 10/100 / 1000Mbps RJ45 LAN Port (Inside of shell)
Page 4 11ac Tri-Band 2200Mbps High Power Outdoor Access Point Model: AP11-Dual-IP67 2.4G Receive 802.11b -85dBm -94dBm Sensitivity 802.11g -72dBm -90dBm 802.11n HT20 MCS7 -70dBm MCS0 -88dBm 802.11n HT40 MCS7 -68dBm MCS0 -86dBm 5G Receive 802.11a -72dBm -90dBm Sensitivity 802.11n HT20 MCS7...
