Trotec PV4-MID-PS Operating Manual page 5

Device depiction
1 2 3 4
6 7 8
Seal
12
13
MID-compliant energy meter
15 16
21
17
18
19
20
21
28
27
EN
5
9 10 11
14
22
17
16
31
30
23
29
24
25
26
multiple socket outlet PV4-MID-PS
No.: Designation
1 Sealing cap
2
Test button T
3 MID-compliant energy meter
4 Robust solid rubber housing
5 Safety socket
6 Handle
7 Residual current device
8 Locking lug for sealing cap
9 Eyelet for seal
10 Safety socket cover
11 PlugSafe appliance
12 Seal
13 Anchoring for seal
14 Open end of seal
15 Terminals for neutral conductors
16 Multifunction button
17 Metrological LED
18 Backlit LC display
19 Terminals for S0 output
20 Current and voltage terminals
21 Safety label
22 Pulse value in kWh (metrological LED)
23 Min./reference current (max. continuous current)
24 Nominal voltage/ frequency
25 Connection diagram (1 phase and neutral conductor)
26 Type of protection
27 Serial number
28 MID designation
29 Homologation number
30 Accuracy class
31 Operating temperature range
