Status Instruments DM3600U Manual

Single channel universal input 6 digit indicator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
DM3600U
Single Channel Universal Input 6 Digit Indicator
Status Instruments Ltd, Status Business Park, Tewkesbury, Glos. GL20 8FD
Tel: +44 (0)1684 296818
Email: sales@status.co.uk
Important - Please read this document
52-314-2367-02
Fax: +44 (0)1684 293746
Web: www.status.co.uk
    before any installing.
Issue: Web 4
I N D E X
SECTION
CONTENTS
1.0
2.0
3.0
4.0
5.0
6.0
7.0
SPECIFICATION
8.0
9.0
10.0
11.0
12.0
13.0
14.0
15.0
PAGE NO.
1
1
2-3
4-5
5
6-7
7-10
10-11
11-12
13
13
14-17
18-20
21-22
23
