- Page 1 Operating instructions Gateway ZB0929...
- Page 2 1 Preliminary note Technical data, approvals, accessories and further information at www.ifm.com. 2 Safety instructions • Read this document before setting up the product and keep it during the entire service life. • The product must be suitable for the corresponding applications and environmental conditions without any restrictions.
- Page 3 2.1 Symbols used ► Instruction > Reaction, result → Cross-reference Important note Non-compliance may result in malfunction or interference. Information Supplementary note. 3 Functions and features • The gateway transmits sensor data to the back-end system. In the back- end system, the sensor data is made available to carry out analyses and evaluations and to create alarm rules.
- Page 4 5 Operating and display elements 1: USB connection 2: Mains connection 3: Ethernet connection 4: Micro-SIM card slot 5: Confi guration button 6 Electrical connection ► Connect the device with the supplied power supply. 7 Set-up The unit switches on automatically when connected to the power supply.
- Page 5 Colour Status Meaning green Device is connected to the Internet. blue Wireless connection to the Internet is being established. flashes The device is in local configuration mode. Device fault ► Open configuration mode and examine the malfunction. 7.1 Connect to the Internet A connection via Ethernet or mobile radio automatically disables the wireless LAN connection.
- Page 6 ► Check connection and position the unit closer to the gateway. Switch off the sensor: ► press button for 30 s. You will find detailed information about the sensors at www.ifm.com. 8 Maintenance, repair, disposal The operation of the unit is maintenance-free. It is not possible to repair the unit.
- Page 7 The overview of the approval status of a device is available on our website at www.ifm.com. 9.2 Europe / EU Declaration of Conformity ifm electronic gmbh hereby declares that the device corresponds to the directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following Internet address: www.ifm.com.
- Page 8 Information to the user: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
