Blaupunkt PSA RD4 LEVEL2 BASIC Circuit Diagram page 12

H3305 H3307
LOT670K2 LOT670K2
AUDIO SOURCE
H3303 H3306
LOT670K2 LOT670K2
TRIP BAND MENU
H3302 H3308
LOT670K2 LOT670K2
CLIM DARK TONE
R3302 R3304 R3306
1K 1K 1K
V3303 V3305
BC848C BC848C
R3303 R3305
180 180
R3329
nb.
5,6K
Iluminationclass
R3321/22/23 n.b. J1 9583
R3321 150 kohm J2 9582
R3322 47 kohm K1 9581
R3323 0 ohm K2 9580
H3309 H3322 H3301
LOT670K2 LOT670K2 LOT670K2
ESC OK EJECT
H3304 H3311 H3310
LOT670K2 LOT670K2 LOT670K2
<<
H3321 H3312 H3315
LOT670K2 LOT670K2 LOT670K2
>>
R3308 R3310
1K 1K
V3307 V3309 V3311
BC848C BC848C BC848C
R3307 R3309 R3311
180 180 180
R3324
150
R3325
150
LOT670K2
H3300
CORONA
R3318
1K
V3319
BC848C
R3319
180
H3313 H3323 H3317
LOT670K2 LOT670K2 LOT670K2
TA 1 2
H3314
H3318 H3319
LOT670K2
LOT670K2 LOT670K2
LIST 3 4
H3316 H3320 H3324
LOT670K2 LOT670K2 LOT670K2
PTY 5 6
R3312 R3314 R3316
1K 1K 1K
V3313 V3315
BC848C BC848C
R3313 R3315
180 180
SCAN 0
S3301_1 S3305_1
ESC
EJECT AUDIO
S3301 S3305
STROBE 0
S3302_1 S3306_1
CLIM
S3302 BAND S3306
STROBE 1
S3303_1 S3307_1
TRIP S3303 SOURCE S3307 <<
STROBE 2
S3304_1 S3308_1
MENU S3304 DARK S3308
STROBE 3
S3321_1
TONE S3321 OK
STROBE 4
LED-ID
R3321 150k
R3322 47k
R3323 0
V3317
BC848C
R3317
180
SCAN 1
SCAN 2
SCAN 3
S3309_1 S3313_1 S3317_1
4
TA
S3309 S3313 S3317
S3310-1 S3314_1 S3318_1
S3310 LIST S3314 2 S3318
S3311_1 S3315_1 S3319_1
S3311 >> S3315 5 S3319
S3312_1 S3316_1 S3320_1
S3312 PTY S3316 3 S3320
S3322_1 S3323_1 S3324_1
S3322 1 S3323 6 S3324
SCHALTERPLATTE
KEY BOARD
J2
X3301
K1
1
K2
2
3
DIM_KEYS_PWM_OUT
4
U141
5
LED-DETECT
6 KBD_X0
7
KBD_0X
8
KBD_1X
9
KBD_2X
10
KBD_3X
11
KBD_4X
12
KBD_X1
13 KBD_X2
14
KBD_X3
15
KBD_X4
16
HMI_ENC2
17
HMI_ENC1
R3301 47k
18
CAP_DETECT
19
PWR_ON_KEY
ID-Platte
20
PWR_ON_KEY / VOLUME
S3300
5 4
S COM
3 1
2
A B
6 7
EVEVOOPF516B
DM1
Data-
1
Matrix-
Code
DM2
Data-
1 Matrix-
Code
PL 9095 D05
