- Page 1 Radio / Cassette Bologna RCR 126 Operating instructions...
-
Page 3: Table Of Contents
Contents Short instructions ... 19 Important notes ... 22 Precautions ... 22 Traffic safety ... 22 Installation/Connection ... 23 Anti-theft protection ... 23 Release panel ... 23 Detaching the release panel ... 23 Fitting the release panel ... 23 Security code ... 23 Entry of a wrong code number ... -
Page 4: Short Instructions
Short instructions 1 On Volume This unit can also be switched on and off with the Release Panel B. Also, when being connected correctly, you may turn the radio on and off via the ignition of your car. Use one of the following possibilities to continue operating the set when the ignition is switched off: a) Switch on/off with knob 1. - Page 5 4 DSC (Direct Software Control) Use the DSC function to customise certain programmable, basic settings to suit your personal needs and prefe- rences. See chapter “DSC pro- gramming” for more information. 5 AF - Alternative frequency during RDS operation When “AF” lights up in the display, the radio will automatically search for a frequency offering better reception of the same RDS programme.
- Page 6 ; PROG button/Fast winding To switch to the other side of the cassette tape: Press both buttons simultaneously. The display shows TR1-PLAY or TR2-PLAY. Fast winding FR : Fast rewind; stop by pressing FF. FF : Fast forward; stop by pressing FR. <...
-
Page 7: Important Notes
B RELEASE / CODE-LED Release panel - detachable face. For extra anti-theft protection, you should take the detachable face with you when leaving your car. To remove it: Press RELEASE. To re-install the panel: Insert on the left side first with the cassette slot facing up and then press on the right until the panel locks in. -
Page 8: Installation/Connection
Do not connect the loudspeaker outputs to ground! Use only the accessory and replacement parts approved by Blaupunkt. Anti-theft protection Release panel This unit is equipped with a release panel (detachable face). -
Page 9: Switching On Security Coding
Briefly press preset button 1; the dis- play shows “0000”. • Enter the code number given in the Blaupunkt car radio passport: Example: The code number is 2521. - Press preset button 1 twice; the dis- play shows “2000”. - Press preset button 2 five times; the display shows “2500”. -
Page 10: Radio Operation With Rds
Permanent 12 V supply and the + ignition lead must be connected correctly (as illustra- ted in the installations instructions). „LED 1“ must be adjusted in the DSC mode. Read “DSC programming - CODE-LED”. Radio operation with RDS (Radio Data System) The Radio Data System offers you more convenience when listening to FM radio sta- tions. -
Page 11: Selecting A Waveband
take advantage of the full RDS service, switch to “REG OFF”. • Press the REG button briefly. When active, “REG ON” will be briefly dis- played each time the radio is switched on. Selecting a waveband With this car radio you can select between the following wavebands: FM 87.5 - 108 MHz MW 531 - 1602 kHz... -
Page 12: Storing Stations
Storing stations On FM, you can store six stations on the preset buttons 1 to 6 for each of the memory banks I, II and T. On MW/LW, you can store six stations each. • Select the waveband with FM or M•L and on FM also the desired memory bank (with FM... -
Page 13: Scanning Stations With Radio-Scan
Scanning stations with Radio-Scan Beginning with the station currently tuned in, you can scan the waveband. The radio will play each station for 8 seconds. To start the scan: • Press SC briefly. The scanned frequency or the station name will start flashing in the display. During the actual scanning process “SCAN”... -
Page 14: Receiving Traffic Programme Stations With Rds-Eon
Receiving traffic programme stations with RDS-EON Many FM broadcasters offer traffic messa- ges for their service area at regular intervals. All traffic programme stations transmit a spe- cial carrier signal alongside their program- mes, which is decoded by your car radio. If this signal is identified, “TP”... -
Page 15: Tape Operation
Tape operation Inserting a tape • Turn on the set. • Insert a tape. Insert the tape with side A or 1 showing up, the open side facing to the right. = Press to eject the tape. The tape will be played in the direction used last. -
Page 16: Dsc Programming
DSC programming DSC (Direct Software Control) allows you to customise certain programmable, basic set- tings to suit your personal needs and prefe- rences and then store them. The basic settings for this audio equipment were made at the factory. In the following you can find an overview of these settings, so that you can always reset to these if desired. -
Page 17: Overview Of The Dsc Factory Settings
Overview of the DSC factory settings TA VOL BEEP LED (Code) : 1 LOUD : OFF LOCAL Appendix Care notes Release panel To ensure that the unit functions properly it is important that the contacts between the re- lease panel and the head unit are free from any foreign particles. - Page 18 Blaupunkt-Werke GmbH Bosch Gruppe 5/96 K7/VKD 8 622 400 771...
