TrueNet Workstation Solutions
Workstation Faceplates and Surface Mount Boxes
Modular Furniture Faceplates
TrueNet modular furniture faceplates are compatible with leading office furniture and accept TrueNet
modular jacks and connectors. Contact ADC Technical Assistance Center for specific model compatibility.
O r d e r i n g I n f o r m a t i o n
Description
2-port horizontal faceplate
Designed for horizontal orientation;
features 1 outlet labeling area, 2
individual port ID areas, ID tabs hide
faceplate mounting screws.
Includes 2 blank paper labels, 1 clear
plastic label protectors, reversible-icon
ID tabs numbered 1-6 (icon colors
match faceplate), mounting screws
(#6-32x15/16" with custom head)
3-port modular furniture faceplate
Recommended opening: 2.65"
x 1.377" (67.31 x 34.98 mm).
Maximum thickness: 0.06" (1.52 mm).
Contains 3 individual port ID areas;
includes 6 reversible-icon ID tabs
numbered 1-6 (icon colors match
faceplate)
4-port modular furniture faceplate
Fits openings: 1.890" x 1.920" (48 x
48.77 mm) high. 2.572" to 3.866"
(65.33 to 98.2 mm) wide.
Maximum thickness: 0.08" (2.03 mm).
Features 1 outlet labeling area, 4
individual port ID areas; includes 2
blank paper labels, 1 clear plastic
label protector, 1 logo insert, 6
reversible-icon ID tabs numbered 1-6
(icon colors match faceplate)
4-Port Beltline Adapter for
Herman Miller Ethospace furniture
Replace XX in catalog number to indicate color:
1
01 = White
w w w . a d c . c o m
2.75" x 4.5" x 0.25"
(69.85 x 114.3 x 6.35 mm)
1.61" x 3.13" x 0.38"
(40.9 x 79.5 x 9.65 mm)
2.17" x 3.9" x 0.38"
(55.12 x 99 x 9.65 mm)
2.45" x 4.20" x 0.36"
02 = Ivory
+ 1 - 9 5 2 - 9 3 8 - 8 0 8 0
Catalog
Dimensions
Number
6644 1 112-XX
6644 1 143-XX
6644 1 144-XX
6644 3 299-XX
03 = Gray
04 = Black
1 - 8 0 0 - 3 6 6 - 3 8 9 1
Modular
Furniture
1
Compatibility
Fits standard
NEMA openings in
modular furniture
raceways or
standard single-
gang boxes
Steelcase 9000,
Steelcase Avenir,
Steelcase Context,
AllSteel 8000, Knoll
Morrison, Knoll Reff,
Haworth Places and
Unigroup, Haworth
Places, Haworth
Premise, Haworth
Race
Herman Miller
- Action Office 1,
Herman Miller
- Action Office 2,
Herman Miller
- Action Office 3,
Herman Miller
- Ethospace
(baseline), Herman
Miller, Phoenix,
Kimball
Herman Miller -
Ethospace
3
