A
DVANCED
The PLX51-PBS Advanced configuration is opened by either double-clicking on the module in
the tree, or right-clicking the module and selecting Configuration. Then select the Advanced
tab.
Figure 3.25 – PLX51-PBS Advanced configuration
The Advanced configuration consists of the following parameters:
Parameter
DLR Enable
NTP Enable
NTP – Server IP Address
NTP – Update Interval
Setup
Description
This must be set to enable Device Level Ring operation when the PLX51-
PBS is operating in an Ethernet DLR.
The PLX51-PBS can synchronize its onboard clock to an NTP Server by
enabling NTP.
This setting is the IP address of the NTP Server which will be used as a
time source.
This setting is the updated interval (in seconds) that the PLX51-PBS will
request time from the NTP Server.
Table 3.6 - Advanced configuration parameters
Page 30 of 111
