Keysight ixia Application Server Installation Manual page 15

Chapter 1 Ixia Application Server Installation
Table: Specifications
Ixia Application Server
Motherboard Dual-processor motherboard using Intel C610-series chipset.
Processor 2 x Intel Xeon processor E5-2600 v3 product family.
Memory 64GB RDIMM, 2133 MT/s, Dual Rank.
Drives One 1TB SATA 6Gbps 3.5 inch hot-plug hard-drive
One 480GB Solid State Drive 6Gbps 2.5 inch hot-plug drive
I/O Ports Rear panel ports: COM port, VGA port, USB and USB 3.0 ports
Front panel ports: VGA port, DVD drive
Ethernet 4 x 1 Gigabit Ethernet ports.
Ports
System 2 x 550W power supply units, 100-240VAC, 50/60Hz, 3.7A-7.4A.
Power
Control LEDs indicate power on, network activity, hard disk drive activity, overheat warning,
Panel and fan failure; control panel also includes a main power button and a reset button.
Cooling 6x high-efficiency fans.
System
Physical Dimensions (WxHxD) 17.2 x 1.7 x 25.4 in. (437 x 43 x 645 mm)
Weight: 27 lbs (12.25 kg), Shipping Weight: 47.45 lbs (21.7 kg)
Operating Up to 35°C (95°F) maximum temperature is reduced by 1°C/300m (1°F/547 ft) above
Environment 950m (3,117 ft).
Operating Microsoft Windows Server 2012 64-bit Standard Edition with 10 remote desktop user
System licenses.
Rackmount Rails for tool-less mounting in 4-post racks with square or unthreaded round holes, or
Kit tooled mounting in 4-post threaded hole racks, with support for optional tool-less
cable management arm.
Application 10 Users on the following applications:
Support
IxNetwork
IxLoad
IxOS
