- Page 1 Application Server Release 9.10 Installation Guide Document version: 202007160823+05:30...
- Page 2 Accordingly, Keysight provides elsewhere in the EULA. future editions. Further, to the the Software to U.S. Keysight shall be under no maximum extent permitted by government customers under obligation to update, revise or applicable law, Keysight its standard commercial otherwise modify the Software.
- Page 3 A CAUTION notice denotes a hazardous situation that, if not avoided, could result in minor or moderate injury. A WARNING notice denotes a hazardous situation that, if not avoided, could result in death or serious injury. – iii –...
- Page 4 Contact Us Ixia headquarters 26601 West Agoura Road Calabasas, California 91302 +1 877 367 4942 – Toll-free North America +1 818 871 1800 – Outside North America +1.818.871.1805 – Fax www.ixiacom.com/contact/info Support Global Support +1 818 595 2599 support@ixiacom.com Regional and local support contacts: APAC Support +91 80 4939 6410 support@ixiacom.com...
-
Page 5: Documentation Conventions
Documentation conventions Documentation conventions The following documentation conventions are used in this guide: Describing interactions with the UI You can interact with products by using different input methods: keyboard, mouse, touch, and more. So in most parts of the user documentation, generic verbs have been used that work with any input method. -
Page 6: Table Of Contents
Documentation conventions About this guide Note icons and messages Typographical conventions Textual conventions Chapter 1 Ixia Application Server Installation Note Regarding Ixia Applications Supported Applications Overview and Specifications Installation and Setup Overview Unpacking the System Preparing for Setup Choosing a Setup Location... - Page 7 General Safety Precautions ESD Precautions Operating Precautions Onboard Battery Replacement Chapter 2 Ixia Application Server Settings Remote Desktop Usage Logging In to the Ixia Application Server User Account Settings Chapter 3 Running Ixia Applications Configuration Multi-User Support Known Limitations Installation...
- Page 8 INDEX – viii –...
- Page 9 This page intentionally left blank. – ix –...
-
Page 10: About This Guide
About this guide This section explains the notational and typographical conventions used in this documentation, and provides a list of related documentation. Section contents: Note icons and messages Typographical conventions Textual conventions – 1 –... -
Page 11: Note Icons And Messages
About this guide Note icons and messages The following table describes the note icons and messages used in this document. Name Icon Description Note Indicates information that emphasizes or supplements important points in the main text. Important Indicates information that is essential to the completion of a task. Provides supplemental suggestions for applying techniques and procedures to accomplish a task. -
Page 12: Textual Conventions
About this guide Textual conventions The following table describes the typographical conventions used in this document. Convention Description Boolean text Words that represent Boolean notation are written in all uppercase text. For example: 192.168.5.5 OR 10.20.30.30. Keystrokes Simultaneous keystrokes are shown by joining the key names with a plus sign (+). - Page 13 This page intentionally left blank. – 4 –...
-
Page 14: Chapter 1 Ixia Application Server Installation
It optimizes and enhances Ixia test application performance by running Ixia applications, in a server-based environment. Connection via Microsoft's remote desktop (RDT) facility provides access to the test applications on the server, minimizing client requirements. The Ixia Application Server centralizes application updates and installation, simplifying test-environment management. - Page 15 Chapter 1 Ixia Application Server Installation Table: Specifications Ixia Application Server Motherboard Dual-processor motherboard using Intel C610-series chipset. Processor 2 x Intel Xeon processor E5-2600 v3 product family. Memory 64GB RDIMM, 2133 MT/s, Dual Rank. Drives One 1TB SATA 6Gbps 3.5 inch hot-plug hard-drive One 480GB Solid State Drive 6Gbps 2.5 inch hot-plug drive...
-
Page 16: Installation And Setup
Unpacking the System Inspect the box the Ixia Application Server was shipped in and note if it was damaged in any way. If the server itself shows damage you should file a damage claim with the carrier who delivered it. Decide on a suitable location for the rack unit that will hold the Ixia Application Server. -
Page 17: Installer Precautions
(that is, the use of power strips). Installing the System into a Rack This section provides information on installing the Ixia Application Server into a rack unit with the rack rails provided. – 8 –... -
Page 18: Identifying The Sections Of The Rack Rails
Chapter 1 Ixia Application Server Installation There are a variety of rack units on the market and the assembly procedure may differ slightly. You should also refer to the installation instructions that came with the rack unit you are using. -
Page 19: Installing The Server Into The Rack
Chapter 1 Ixia Application Server Installation Note: Both chassis rails have a locking tab, which serves two functions. The first is to lock the server into place when installed and pushed fully into the rack, which is its normal position. -
Page 20: Installing A Server Into A Telco Rack
Figure: Installing the Server into a Rack Installing a Server into a Telco Rack To install the Ixia Application Server into a Telco type rack, do the following: 1. Use two L-shaped brackets on either side of the chassis. 2. Determine how far follow the server will extend out the front of the rack. Larger chassis should be positioned to balance the weight between front and back. -
Page 21: Providing Power
Chapter 1 Ixia Application Server Installation Figure: Installing the Server into a Telco Rack Providing Power The final step is to provide input power to the system. Plug the power cord from the power supply unit into a high-quality power strip that offers protection from electrical noise and power surges. -
Page 22: Overview
Chapter 1 Ixia Application Server Installation Overview There are several LEDs on the control panel to keep you constantly informed of the overall status of the system as well as the activity and health of specific components. There are also two buttons on the chassis control panel. -
Page 23: Safety Precautions
Chapter 1 Ixia Application Server Installation Control / Indicator Description LAN2 When flashing, indicates network activity on LAN2. Channel activity for all hard disks. When flashing, this light indicates DVD-ROM or IDE drive activity. Power Indicates power is being supplied to the system's power supply units. This LED should (LED) normally be illuminated when the system is operating. -
Page 24: General Safety Precautions
Keep the area around the Ixia Application Server clean and free of clutter. The Ixia Application Server weighs approximately 23 lbs to 27 lbs (10.4 kg to 12.2 kg) when fully loaded. When lifting the system, always keep your back straight and lift with your legs. - Page 25 Chapter 1 Ixia Application Server Installation Figure: Onboard Battery Replacement shows the proper orientation of the onboard lithium battery. There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarity. Figure: Onboard Battery Replacement...
-
Page 26: Chapter 2 Ixia Application Server Settings
Logging In to the Ixia Application Server To log in to the Ixia Application Server via remote desktop, use the two Remote Desktop license cards pre-installed with the application server. To install additional RD CALs (Client Access Licenses): 1. - Page 27 Chapter 2 Ixia Application Server Settings run applications. It is advised that you change the Admin account names for security reasons. The default password for the Administrator account should be left unchanged to provide access to the server for debug purposes.
- Page 28 Chapter 2 Ixia Application Server Settings Account Name Password User02 123456-02 User03 123456-03 User04 123456-04 User05 123456-05 User06 123456-06 User07 123456-07 User08 123456-08 User09 123456-09 User10 123456-10 – 19 –...
- Page 29 This page intentionally left blank. – 20 –...
-
Page 30: Chapter 3 Running Ixia Applications
Supports disconnect/reconnect from the test session in progress Configuration The Ixia chassis, the Ixia Application Server, and the end-users’ computers are all connected via a corporate intranet or internet. Ixia test applications will be installed only on the Ixia Application Server. -
Page 31: Multi-User Support
Figure: Typical Multi-User Configuration Multi-User Support The configuration below supports multiple users running the Ixia application from the High- Performance Ixia Application Server: Each login user needs to have “Administrator” and “Remote Desktop Users” privilege to run the Ixia application. - Page 32 Chapter 3 Running Ixia Applications Each instance of the Ixia application and remote desktop session can be viewed and controlled by other users if permission is granted by the login user. The following quick steps show how to do this: 1.
-
Page 33: Known Limitations
Known Limitations Installation When installing an Ixia application on the Ixia Application Server, only console mode is allowed. Remote Desktop Session is not able to install all required components (and no error message will be given). Ixia recommends VNC service to be used for remote installation. -
Page 34: Ixautomate
The saved configuration for IxAutomate, along with its log files and result files, is saved in the same directory on the Ixia Application Server. The config files for each user will be applied to each instance of IxAutomate on the application server. Each user must carefully name the config files based on the user’s login name. - Page 35 This page intentionally left blank. – 26 –...
- Page 36 17 running installation 24 Ixia applications 21 installation and setup 7 ixia application 24 safety precautions 14 Ixia Application Server 5, 7, 17 supported 5 keyboard interactions v touch interactions v known limitations 24 typographical conventions 2 limitations-known 24...
- Page 37 © Keysight Technologies, 2020 Ixia, a Keysight Business 26601 West Agoura Road Calabasas, California 91302...
