- Page 1 MTS-ZB RENOGY Photovoltaic Module Z-Bracket Mounting System 2775 E Philadelphia St, Ontario, CA 91761 1-800-330-8678...
- Page 2 Important Safety Instructions Please save these instructions. This manual contains important safety, installation, and operating instructions for the Renogy Z- Bracket Mount hardware system. The following symbols are used throughout the manual to indicate potentially dangerous conditions or important safety information.
-
Page 3: Table Of Contents
Table of Contents General Information ...................... 4 Identification of Parts ....................5 Installation ........................7 Mating Brackets to Panel Frame ................9 Install of Panel to General Mounting Surface ............12 Install of Panel to RV Roofs ................... 17 Z-Bracket Dimensions ....................25 Compatibility ....................... -
Page 4: General Information
General Information The Renogy Z-Bracket Mount System is designed to support the installation of single panel units, generally in off-grid installations. These units are ideal for installation on RV roofs and non- inhabited dwellings such as sheds or garages. It is also suited as attachment to a user made structure such as a wooden frame. -
Page 5: Identification Of Parts
Identification of Parts Image Component Description Main component. Secures panels to mounting surface using the included fasteners. Z-Bracket Fastener used to secure panel to Z- Bracket. M6 x 16mm Material: Stainless Steel Hex Cap Bolt Deformable washer which creates a spring force from deformation. - Page 6 Screw capable of self-drilling into the mounting surface. Used to secure the Z-Bracket to the mounting surface. #10 x 1¼ in Material: Steel Self-Drilling Cap Screw Placed between the self-drilling screws and the Z-Bracket. Should come Plastic threaded over self-drilling screws in Retaining package.
-
Page 7: Installation
Installation Recommended tools to have before installation: The following tools and equipment are highly recommended to have available to assist with installation but are in no way a comprehensive list of tools that can ease installation. Installers feel free to substitute comparable equipment where appropriate. Image Component Description... - Page 8 Used to ensure panel is level and/or plumb to the mounting surface and orientation. Spirit Level WARNING: Installation on shingle roofs is not recommended. System is not designed with these roof types in mind. Fasteners will not penetrate framing deep enough and will likely cause heavy issues with leaking.
-
Page 9: Mating Brackets To Panel Frame
Mating Brackets to Panel Frame... - Page 10 NOTE: Various solar modules will have different varieties of mounting hole locations. Please align brackets in a way that will evenly support the module.
-
Page 12: Install Of Panel To General Mounting Surface
Repeat for each Z-Bracket in the set at each corner. Install of Panel to General Mounting Surface... - Page 13 NOTE: Ensure screw locations are backed by structural element such as a rafter, stud, etc.
- Page 15 NOTE: Orient panel in level/plumb layout desired before fixing in position.
- Page 16 NOTE: Begin new fastener at indicated location first to secure panel in level plumb/level layout. Repeat for all fastener locations.
-
Page 17: Install Of Panel To Rv Roofs
NOTE: Seal around all edges of bracket and screws. Repeat for all brackets. Install of Panel to RV Roofs Installation on to the roofs of RV’s typically requires more specialized instruction due to the nature of construction of most commercially available RV roofs. Please note that this section includes... - Page 18 the use of a fastener type included in the Z-Bracket kit. This section is included for convenience of customers installing to an RV roof. The instructions listed in this section are a modification of the normal installation, all other steps are to be completed normally. A minimum roof thickness of 3/8”...
- Page 19 Used with Cordless Drill to create clearance holes for the well nuts. Must be Drill Bit matched to the well nut’s outer diameter. Recommended variety requires 3/8” bit.
- Page 20 NOTE: Mark all hole locations in this step as the panel must be removed for well nut insertion.
- Page 22 NOTE: Use of sealant is optional with a well nut but sealing will add extra assurance. Seal under well nut head. Repeat for all holes.
- Page 23 NOTE: Orient panel in level/plumb layout desired before fixing in position.
- Page 24 NOTE: Screw has compressed and expanded the well nut, binding into the roof material. Repeat for all fasteners.
-
Page 25: Z-Bracket Dimensions
Z-Bracket Dimensions NOTE: Dimensions in millimeters. - Page 26 NOTE: Dimensions in inches.
-
Page 27: Compatibility
*This list is not comprehensive and is intended for an “at-a-glance” look at which solar modules provided by Renogy are compatible with the Z-Bracket Mounting System. Modules provided by other manufacturers may work with the Z-Bracket Mounting System provided the follow conditions are met: 1) Solar module weight does not exceed 88 lbs (40 kg) or total load per bracket does not exceed 22 lbs (10 kg).
