- Page 1 Interface RS485-WiFi v.1.1 INTRW CODE: Edition: 3 from 28.05.2015 Supercedes edition: 2 from 05.12.2013...
-
Page 2: Table Of Contents
INTRW CONTENTS 1. General description..........................3 2. Components arrangement........................4 3. Installation............................. 5 Main guidelines................................5 Connection to the RS485 bus............................5 Installation of the interface............................... 5 4. Configuration of the RS485- WiFi interface..................6 Introductory information. -
Page 3: General Description
INTRW Features: wireless connection via Wi-Fi Permission of the Scientific and Research Centre for Fire Protection - National Research Institute for use with power supplies of the EN54 series in fire alarm systems communication in the 2.4GHz band compliant with the IEEE 802.11b/g/n ... -
Page 4: Components Arrangement
INTRW The topology of the network is based on an Ethernet switch (e.g. switch, router) connected to another PSU segments (connected in the RS485 bus) via the RS485-Ethernet interface. Each interface has a static IP address. The communication between the PC and the final PSU requires the IP address of the interface, the address of the PSU in the RS485 bus and the number of the port responsible for the communication. -
Page 5: Installation
INTRW 3. Installation. 3.1 Main guidelines. When installing the RS485-ETHERNET interface, please follow the general rules that will help to avoid electromagnetic interferences and incorrect operation of the device: - supply the interface with the power source of low ripple voltage... -
Page 6: Configuration Of The Rs485- Wifi Interface
Once connected to computer USB port, the interface will be automatically detected by the operating system and the driver installation will follow. If the drivers are not detected by the system, it is suggested to download them from PULSAR website at: http://www.pulsar.pl/pliki/CDM v2.12.00 WHQL Certified.exe... -
Page 7: Step 2 - The Wi-Fi Settings
INTRW Run the configuration program "powerconfig" which enables the connection of the interface and its appropriate configuration. After starting the program, choose the "WiFi" in the "Module type" and then press the "Search" button. The connected module will be displayed in the window. To access the module configuration, check the field under "Type". -
Page 8: Step 3 - The Tcp/Ip Network Settings
INTRW If the network is within range, it can be selected for interface connection after the scan. To do this, press the "Scan" button at the bottom of the window. After pressing the button, the scan is performed and all networks within range are displayed. -
Page 9: Step 4 - Setting The Serial Port Parameters
INTRW 4.5 STEP 4 – Setting the serial port parameters. In the „Serial port” tab, set the parameters responsible for the communication between RS485-WiFi Ethernet interface and the PSU as shown in the picture below. If the PSU does not support the 115 200 baud communication speed or other communication parameters are set, enter the parameters in the „COM port settings”... -
Page 10: Configuration Of Power Supplies
INTRW 5. Configuration of power supplies. 5.1 Configuration of power supplies of the PSBEN series with LCD display. The PSU fitted with LCD display enables setting the communication parameters of the serial port from the LCD panel. To enter the setup mode, press the „SET” button from the main screen. -
Page 11: Configuration Of Power Supplies Of The Psben Series With Led Display
INTRW 5.2 Configuration of power supplies of the PSBEN series with LED display. The PSU is fitted with LED display, which enables setting the communication parameters of the serial port from the LED panel. To enter the setup mode, simultaneously press the „<,>” rightmost and leftmost buttons on the LED panel. -
Page 12: Configuration Of Power Supplies Of The En54 Series With Lcd Display
INTRW 5.3 Configuration of power supplies of the EN54 series with LCD display. The PSU fitted with LCD display enables setting the communication parameters of the serial port from the ”. LCD panel. To enter the setup mode, press the „SET” button from the main screen - use the „<”... -
Page 13: Configuration Of Power Supplies Of The En54 Series With Led Display
INTRW 5.4 Configuration of power supplies of the EN54 series with LED display. The PSU fitted with LED display enables setting the communication parameters of the serial port from the LED panel. To enter the setup mode, simultaneously press the „<,>” rightmost and leftmost buttons on the LED panel. -
Page 14: Configuring The Connection In Powersecurity Program
INTRW 6. Configuring the connection in PowerSecurity program. For further configuration, the PowerSecurity program is required. The program is available on: http://www.pulsar.pl/pliki/PowerSecurity.exe It is an executable file, which does not require installation. 1) Run the PowerSecurity.exe. 2) Choose the Power Supplies > New Power Supply option from the menu bar. The “Configuration of connection”... -
Page 15: Technical Parameters
INTRW remote desktop of PSU EN54 remote desktop of PSU PSBEN menu bar manager window Fig. 6. The preview window of the PSU of the PSBEN (left) and EN54 series (right). More information on the "PowerSecurity" program can be found in the manual which can be downloaded at: http://www.pulsar.pl/pl/opisy/PowerSecurity.pdf... - Page 16 INTRW WEEE LABEL Waste electrical and electronic equipment must not be disposed of with normal household waste. According to the European Union WEEE Directive, waste electrical and electronic equipment should be disposed of separately from normal household waste. Pulsar WARRANTY Siedlec 150, 32-744 Łapczyca, Polska...
