Summary of Contents for Frigicoll WIFI USB 01
- Page 1 OWNER’S MANUAL WiFi Controller WIFI USB 01 IMPORTANT NOTE: Read the manual carefully before intalling or connecting your Smart kit (Wireless module). Make sure to save this manual for future reference.
-
Page 2: Table Of Contents
CONTENTS 1. SPECIFICATION ..................1 2. PRECAUTIONS ..................1 3. DOWNLOAD AND INSTALL APP .............. 2 4. INSTALL THE SMART KIT ................. 3 5. USER REGISTRATION ................4 6. NETWORK CONFIGURATION ..............5 7. HOW TO USE APP .................. 12 8. SPECIAL FUNCTIONS ................14 DECLARATION OF CONFORMITY Hereby, we declare that this Smart kit is in compliace with the essential requirements and other relevant provisions of Directive 2014/53/EU. -
Page 3: Specification
1. SPECIFICATION Model WIFI USB 01 Standard IEEE 802.11 b/g/n Antenna Type Printed PCB Antenna Frequency WLAN 2400 ~ 2483.5 MHz Maximum Transmitted Power 19.8 dBm Max.. Operation Temperature 0ºC~45ºC/32ºF~113ºF Operation Humidity 10%~85% Power Input DC 5 V/300 mA 2. PRECAUTIONS •... -
Page 4: Download And Install App
3. DOWNLOAD AND INSTALL APP Caution: The following QR Code is only available for downloading APP. It is totally different with the QR code packed with SMART KIT. Android • Android Phone users: scan Android QR code or go to Google Play, search ‘NetHome Plus’... -
Page 5: Install The Smart Kit
4. INSTALL THE SMART KIT (wireless module) Remove the protective cap of the smart kit (wireless module) Open the front panel and insert the smart kit (wireless module) into the reserved interface. Attach the QR code packed with Smart kit (wireless module) to the side of the machine, ensure it is convenience to be scanned by the mobile phone. -
Page 6: User Registration
5. USER REGISTRATION • Please ensure your mobile device is connected to Wifi router. Also, the Wifi router has already connected to Internet before doing user registration and network configuration. • It is better to log in your email box and active your registration account by clicking link in case you forget the password. -
Page 7: Network Configuration
6. NETWORK CONFIGURATION CAUTIONS: • It is necessary to forget any other around network and make sure the Android or iOS device just connect to the Wireless network you want to configure, • Make sure the Android or iOS device Wireless function works well and can be connected back to your original Wireless network automatically. - Page 8 5. Press “+ Add Device” 6. Select the appliance you are setting upassword and click “OK”. 7. Follow the above steps to enter “AP” mode...
- Page 9 8. Choose the network 9. Choose the “Scan the configuration QR code” method method 9. Or choose the “Manual 10. Please enter Setup” method password...
- Page 10 12. Configuration Success, 11. Network configuration is you can see the device on the list successful...
- Page 11 Using iOS device to do network configuration: Make sure your mobile device has already been connect to the Wireless network which you want to use, Also, you need to forget other irrelevant Wireless network in case it influences your configuration process. Disconnect the power supply of AC (some units).
- Page 12 7. Follow the above steps to enter “AP” mode 8. Connect to the Wireless 9. Please enter password network...
- Page 13 10. Network configuration 11. Configuration Success, is successful you can see the device on the list. NOTE: • When finishing network configuration, APP will display success cue words on the screen. • Due to different internet environment, it is possible that the device status still display “offline”.
-
Page 14: How To Use App
7. HOW TO USE APP Please ensure both your mobile device and air conditioner are connected to the Internet before using app to control the air conditioner via Internet, please follow the next steps: 1. Click “Sign up” 2. Choose the air conditioner. 3. -
Page 15: Special Functions
8. SPECIAL FUNCTIONS Including: Timer On, Timer Off, 8ºC Heat, Sleep, Check. NOTE: If the air conditioner do not support the above function, the function will be hided from the function list. • Timer On / Timer Off Weekly, user can make an appointment to turn on or off AC on specific time. User also can choose circulation to keep the AC under schedule control every week. - Page 16 • Sleep User can customize their own comfortable sleep by setting target temperature. • Check User can simply check the AC running status with this function. When finishing this procedure, it can display the normal items, abnormal items, and detail information.
- Page 17 • Share Device The air conditioner can be controlled by multi-users at the same time by Share Device function. 1. Click “Share device” 2. QR code display. 3. The other users must log in 4. Now the others can add the ‘Nethome Plus’...
- Page 18 APP DECLARATION FCC ID: 2AS2HMZNA19 IC : 24951-MZNA19 This debice complies with Part 15 of the FCC Rules and Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device Only operate the device in accordance with the instructions supplied.
- Page 19 CS374U-APP(OEM) 16110800000349 20190516 Company will not be liable for any issues and problems caused by Internet, Wireless Router and Smart Devices. Please contact the original provider to get further help.
