OWNER'S MANUAL
Water Heat Exchanger Wire Controller
KWF 140 ACS
Thank you for purchasing our product. Please read this manual carefully before
running the unit and keep it for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Kaysun KWF 140 ACS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigicoll Kaysun KWF 140 ACS

Summary of Contents for Frigicoll Kaysun KWF 140 ACS

  • Page 1 OWNER’S MANUAL Water Heat Exchanger Wire Controller KWF 140 ACS Thank you for purchasing our product. Please read this manual carefully before running the unit and keep it for future reference.

  • Page 2: Table Of Contents

    CONTENTS Safety precautions..........1 Technical data andcharacteristic......2 Overview...............3 Operation instruction..........6 Error handling............. 16 ● This manual gives detailed description of the precautions that should be brought to your attention during operation. ● In order to ensure correct service of the wired controller please read this manual carefully before using the unit.

  • Page 3: Safety Precautions

    Safety precautions WARNING Please assign the distributor or professionals to install the device. Improper installation may lead to electric shock or fire. Do not install the unit in a place vulnerable to leakage of flammable gases. Once flammable gases are leakedand left around the wire controller, fire may occur. Do not operate with wet hands or let water enter the wire controller.

  • Page 4: Technical Data Andcharacteristic

    2. Technical data and characteristic 2.1 Technical data 1) Input voltage : 10VAC. 2) Operating environment temperature of wired controller: -10°C~+43°C. 3) Operating RH of wired controller: RH 40%~RH90%. 2.2 Characteristic 1) Touch key operation; 2) LCD displays operation parameters; 3) Multiple timer;...

  • Page 5: Overview

    3. Overview 3. Présentation 1. Operation icon 7. Water Level Indication 13. FUNCTIONS key 2. Mode area 8. Clock 14. Add and Reduce key 3. Setting temperature 9. Water temp. 15. Cancel key 4. Timing On/Off 10.ON/OFF Key 16. Mode key 5.
  • Page 6 Operation icon : Indicate unit ON and OFF status; the icon displays when the unit is on and does not display when the unit is off; Mode area : Indicate the main unit operating mode ; Setting temperature: 2 status can be displayed: Timing ON/OFF indication : Indicate the timing information ;...
  • Page 7 Right and Left key: Press these keys to check setting water temperature, setting cycle heating water temperature and setting water level under main page; Press right key to shift to the next step setting under timing setting status; Press these keys to turn over the unit parameter information under check status;...

  • Page 8: Operation Instruction

    4. Operation instruction 4.1 Turn On and Turn Off the main unit 1) Press the On/Off key to control On and Off status of the main unit. 2) Under Off status, press the On/Off key “ ” to run the main unit, at that time the LCD of wire controller will display the operation icon “...
  • Page 9 4.2 Setting operating modes and parameters Press “FUNCTIONS” key to enter the operation mode and parameters setting. The setting contents will change as the following order each time the key is pressed: NOTE The setting options in the dotted line frame are not general setting. The wire controller automatically judge the needed setting according to the main unit model 1) Setting water temperature: Press the “▲”...
  • Page 10 2) Set the stop and restart temperature 3) Timing setting: 3 timing periods can be difference (Valid when the wire controller is set on the wire controller: Timer 1, Timer set to 5) 2, Timer 3. These 3 timers can control Continuous press “FUNCTIONS”...
  • Page 11 At this time the hour of the clock will flash, At this time the hour of the clock will which means the current setting is the hour flash, it means the current setting is the of Timer 1 “On”, press the “▲” or “▼” to hour of the Timer 2 “On”.
  • Page 12 Example of Timing setting: Écran principal Main page Appuyez deux fois sur la touche FUNCTIONS pour Press “FUNCTIONS” key twice to enter hour setting entrer dans l'interface du réglage de l'heure de interface of “Timer 1 On” « Timer 1 On ». ▲...
  • Page 13 During any period of timing setting to press “OK” key , the timing periods which have been set will be effective (only if the “On” and “Off” of one timing period have been set, the setting is effective). Check timing information: to check the timing which has been set, press “◄” or “►” key under main page, the “...
  • Page 14 Set working mode (valid when wire controller set to 2,3,4) Press “MODE” key to enter the working mode setting when the main unit is off power. Press the “MODE” key to adjust, press “OK” key or wait for 7 seconds to confirm and back to the main page;...
  • Page 15 Set clock Press the “FUNCTIONS” key 4 times to enter clock setting. The hour of the clock will flash, which means the current setting is the hour of the clock, press the “▲” or “▼” to adjust, press “ ” key when finished, and then the minute of the clock will flash, it means the current setting is the minute of the clock, press the “▲”...
  • Page 16 4.3 Check 1) Check function allows the user to check all the operating parameters, error and protection information of the main unit. 2) Enter method: press and hold “FUNCTIONS” key for 3 seconds to enter check interface, as the figure display: Check icon Main unit sequence number Check...

  • Page 17: Error Handling

    Error handling When the unit has error or protection, “ ” icon will flash. Press and hold “SET” key for 3 seconds to enter check status and then press the “▲” or “▼” key to check the unit of 0-15#. If the “error”...
