Material removed (P/N
& material type)
Screws
0863-002 - Phillips head,
stainless steel, 3 ea
3.4 – Remove EMI shielding
WatchGuard Technologies.
Authorization and Revision History for this document is available in the WatchGuard ECO system
Design for Manufacturing and Environment Document
Instruction visual
Separate PCBA from
chassis bottom
Doc #480-2523-001 Rev. A
Remove PCBA screws -3 ea.
Page 5 of 8
