Installation Guide
Dash & Antenna Bracket
909090
A
QUANTITY
1
Flat Head Screw
909094
F
QUANTITY
2
10-32 Knob w/ Stud 10-32 Knob w/ Insert
PT#
ai.950955
&
ai.951250
BEE III/Enforcer
Assembly
Installation Materials
909092
B
QUANTITY
5
#10 Nylon
Flat Washer
909091
909085
G
QUANTITY
1
Not
Included
908203
C
QUANTITY
3
#10 Flat Washer
H
QUANTITY
1
1/4-20 Star Knob
w/ Insert
908340
903356
D
QUANTITY
1
1/4" Flat Washer
909807G01
909041
I
QUANTITY
1
Antenna Bracket
E
QUANTITY
1
1/4" Nylon
Flat Washer
J
QUANTITY
1
Dash Bracket
Advertisement
Related Manuals for MPH Industries BEE III
Summary of Contents for MPH Industries BEE III
- Page 1 Installation Guide BEE III/Enforcer Dash & Antenna Bracket Assembly Installation Materials 909090 909092 908203 908340 903356 QUANTITY QUANTITY QUANTITY QUANTITY QUANTITY #10 Nylon 1/4” Nylon Flat Head Screw Flat Washer #10 Flat Washer 1/4” Flat Washer Flat Washer 909094 909091...
- Page 2 Installation Process Insert screw (A) into hole in bracket. Slide nylon washer (B) onto screw. Place antenna bracket (I) onto screw. Slide nylon washer (B) onto screw. Place radar onto bracket. Slide flat washer (C) onto screw. Thread knob (G) onto screw, but do not fully tighten. Take knob with stud (F) and slide a flat washer (C) and a nylon washer (B) onto stud.
