Unite CDD | CDS Cockpit Charger | Unite DS Basic Charger
Rear view of Unite CDS-4/2 | Unite CDD-8/4
Unite CDD-8/4
Unite CDD-8/4
Operating control LED
Button to start the pairing process or to clear saved pairing information in the charger
Status display for pairing status and automatic pairing process
Button for automatic pairing process
Reset button for restoring the factory IP address setting
Ethernet connection
USB-C connection
12 V DC connection for power supply unit
Important:
• CDS-4/2: Please use only the supplied XP Power VET36US120C2-JA power supply unit!
• CDD-8/4: Please use only the supplied XP Power VEC50US12 power supply unit!
