5. How to operate the charger
The Unite CDD-8/4 and Unite CDS-4/2 Cockpit chargers are used to charge the batteries in the Unite
transmitters and receivers and to transfer the pairing information from the transmitters to the receivers.
• The Unite CDD-8/4 Cockpit desktop charger has 8 charging compartments of which 4 are combined
compartments for charging a handheld transmitter or bodypack device.
• The Unite CDS-4/2 Cockpit desktop charger has 4 charging compartments of which 2 are combined
compartments for charging a handheld transmitter or bodypack device.
• The Unite DS-4/2 desktop charger is only used for charging the batteries in the transmitters and recei-
vers. It has 4 charging compartments of which 2 are combined compartments for charging a handheld
transmitter or bodypack device.
5.1

Mains connection

• Connect the AC adapter with the power plug to a power outlet and with the DC plug to a 12 V DC
socket of the charger.
• The charger has no separate on/off switch and is immediately ready for use.
• When the device is not in use, remove the mains plug from the power outlet. Make sure that you do not
pull on the cable, but on the power plug.
• Make sure that you connect only the supplied power supply unit to the Unite CDD-8/4, Unite CDS-4/2 and
Unite DS-4/2 charger (refer also to "Supplied accessories"). The internal pin of the DC socket of the Unite
CDD-8/4 has a different diameter as the pin of the DC socket of the Unite CDS-4/2.
