REGISTER NOW TO
5
ACTIVATE YOUR
YEAR
WARRANTY*
www.purpleline.co.uk
01473 601200
design...innovate...improve
TWIN AXLE WHEEL LOCK
UK
Installation guide and user manual
*WARRANTY REGISTRATION MUST BE COMPLETED WITHIN 14 DAYS OF PURCHASE
Twin Axle Wheel Lock
PRODUCT CODE: FGT400
FGT400-UM-04/2020
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Purple Line fullstop GEMINI
Summary of Contents for Purple Line fullstop GEMINI
- Page 1 REGISTER NOW TO Twin Axle Wheel Lock ACTIVATE YOUR PRODUCT CODE: FGT400 YEAR WARRANTY* www.purpleline.co.uk 01473 601200 design...innovate...improve TWIN AXLE WHEEL LOCK Installation guide and user manual *WARRANTY REGISTRATION MUST BE COMPLETED WITHIN 14 DAYS OF PURCHASE FGT400-UM-04/2020...
- Page 2 PARTS IDENTIFICATION & FITTING DIAGRAM Fig. A Outer Tube Fig. B Inner Tube Locking Portion (x2) 1mm Spacer Ring (x50) Locking Portion Hex Screw (x2) 3mm Hex Key Key (x6) 19mm Wheel Wrench Adapter M12 Standard Receiver Wheel Bolt (x2) M12 Long Receiver Wheel Bolt (x2) Fig.
- Page 3 Fig. D INSTALLATION The FullStop Gemini Wheel Lock is designed to secure twin axle caravans and trailers by locking onto both ® axles via replacement wheel bolts. Fixed securely to both axles, the Gemini then prohibits normal wheel rotation and consequent movement of the vehicle. Before the product can be used, two of your existing Fig.
- Page 4 INSTALLATION (CONT.) To prepare the Gemini for fitting, the required length must first be determined and adjusted accordingly. To do this, both Locking Portions (3) will need installing for use as guides. Using Fig.A for reference, install the Locking Portions (3) into apertures in the head of both the Outer (1) and Inner Tubes (2). Each Locking Portion (3) can then be secured in place by tightening the Locking Portion Hex Screw (5) using the supplied 3mm Hex Key (6) (see Fig.A for reference).
- Page 5 INSTALLATION (CONT.) NOTE: If at this stage you find that the Standard Receiver Bolts (9) do not protrude far enough from the wheel to achieve a flush fit of the Gemini Lock with the wheels, it may be that you require the provided longer Receiver Bolts (10).
- Page 6 No form of consequential loss what so ever will be accepted. © Copyright 2020. Purple Line Limited, Peninsula Business Centre, Wherstead, Suffolk, IP9 2BB, UK www.purpleline.co.uk +44 1473 601200 Photographs for illustration purposes only.
