Use both hands to open the door more
3.
than 90°. Lift it up and take it off.
4. Remove the 4 hex head bolts hinges (E)
with an Allen wrench (5/32",4mm).
Remove the lower left and right door
hinges (F).
F
E
Disassembling the freezer door
1.
Pull out the freezer door and the upper
freezer drawer (G) to the final position.
2.
Take out the ice storage box (H) by
lifting it up in the direction of the arrow.
3.
Take out the upper freezer drawer (G)
by lifting it up from the rail system.
G
H
G
6
